(3) Down setting button

(7) Child lock symbol

(4) On/Off button

3.2 Temperature display

The following are displayed in normal operation:

-

the average cooling temperature

The  following  displays  indicate  malfunction.  Possible  causes

and corrective action (see Malfunction).

-

F0

 to

F5

4 Putting into operation

4.1 Transporting the appliance

CAUTION

Risk  of  injury  and  danger  of  damage  as  a  result  of  incorrect

transport!

u

Transport the appliance in a packed condition.

u

Transport the appliance upright.

u

Do not transport the appliance without assistance.

4.2 Installing the appliance

In the event that the appliance is damaged, contact the supplier

immediately before connecting to the mains.
The floor at the site must be flat and level.
Do not install the appliance in a location where it is exposed to

direct radiation of the sun, next to a cooker, heater and similar.
Do not install the appliance without assistance.
Standard  EN  378  specifies  that  the  room  in  which  you  install

your  appliance  must  have  a  volume  of  1  m

2

  per  8  g  of  R  600a

refrigerant used in the appliance. If the room in which the appli-

ance  is  installed  is  too  small,  a  flammable  gas-air  mixture  may

form  in  the  event  of  a  leakage  in  the  refrigeration  circuit.  The

quantity of refrigerant used in your appliance is indicated on the

type plate on the inside of the appliance.
Fit the appliance in stable kitchen units only.
The following ventilation gaps must be observed:

q

The  depth  of  the  ventilation  channel  at  the  rear  of  the  unit

must be at least 38 mm.

q

There must be a ventilation space of at least 200 cm

2

 in the

plinth and at the top of the unit.

q

Basically  the  principle  applies:  the  larger  the  ventilation

space, the more energy-saving the appliance is in operation.

WARNING

Fire hazard due to dampness!

If  live  parts  or  the  mains  lead  become  damp  this  may  cause

short circuits.

u

The appliance is designed for use in enclosed areas. Do not

operate  the  appliance  outdoors  or  in  areas  where  it  is

exposed to splash water or damp conditions.

WARNING

Fire hazard due to refrigerant!

The  refrigerant  R  600a  is  environmentally  friendly  but  flam-

mable. Escaping refrigerant may ignite.

u

Do not damage the piping of the refrigeration circuit.

WARNING

Fire hazard and danger of damage!

u

Do  not  place  appliances  emitting  heat  e.g.  microwaves,

toasters etc. on the appliance!

u

Detach the connecting cable from the rear of the appliance,

removing  the  cable  holder  at  the  same  time  because  other-

wise there will be vibratory noise!

After installation:

u

Remove the protective film from the decorative trims.*

u

Remove all transit supports.

u

Unscrew  the  red  transport

lock.  Close  the  vacated

retaining  hole  using  the

stopper (60).*

*

u

Dispose of packaging material (see 4.3) .

NOTICE*

Risk of damage due to condensate!

If your appliance is not a Side-by-Side (SBS) appliance:

u

do not install the appliance directly alongside a further refrig-

erator/freezer.

Note

u

Clean the appliance (see 6.2) .

If  the  appliance  is  installed  in  a  very  damp  environment,

condensate may form on the outside of the appliance.

u

Always see to good ventilation at the installation site.

4.3 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.4 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.

Putting into operation

4
