5.1.1 Muting the temperature alarm*

The  audible  alarm  can  be  muted.  When  the  temperature  is

sufficiently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 2 (4).

w

The audible alarm is silenced.

5.2 Freezing food

The  rating  plate  indicates  the  maximum  quantity  of  fresh  food

you  can  freeze  within  24  hours  (see  Appliance  at  a  glance)

under "Freezing capacity ... kg/24h".
The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.
A  vacuum  is  generated  after  the  door  is  closed.  After  closing

the door, wait for about 1 minute and then it opens more easily.

CAUTION

Risk of injury due to broken glass!

Bottles  and  cans  containing  drinks  may  burst  when  being

frozen. This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In  order  that  the  food  is  rapidly  frozen  through  to  the  core,  do

not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.3 Thawing food

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.4 Setting the temperature

The  temperature  can  be  set  between  the  first  point  (warmest

temperature,  lowest  refrigerating  capacity)  and  max.  (coldest

temperature, highest refrigerating capacity), the recommended

temperature is-18 °C i.e. the 3rd point.

u

Turn  the  temperature  control

  Fig.  2  (1)  with  a  coin  until  the

temperature wanted lights up in the temperature display.*

-or-

u

Turn the temperature

 Fig. 2 (1) control to the 3rd point.

The temperature is dependent on the following factors:

the frequency of door opening

the room temperature of the installation site

the type, temperature and quantity of frozen food

u

You  may  have  to  readjust  the  temperature,  depending  on

the temperature wanted.

if the freezer is relatively empty:

u

readjust temperature after 6 h.

if the freezer is full:

u

readjust temperature after 24 h.

The temperature can be set slightly colder within a temperature

range, e. g. –15 °C to –18 °C or between two control settings.

u

If required, slowly turn the temperature control further.

w

The  lit  bar  of  the  temperature  range,  e.  g.  –18  °C  flashes

briefly.  The  temperature  within  the  temperature  range  was

set colder.*

5.5 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
In  addition,  frozen  food  already  in  storage  is  given  a  "cold

reserve".  The  food  stays  frozen  longer  as  a  result  when  you

defrost the appliance.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

5.5.1 Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 2 (2).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the bottom drawers.

In  case  of  the  maximum  amount  of  food  to  be  frozen  (see

type plate):

u

wait about 24 h.

u

Place wrapped food straight onto the shelves and put it into

the drawers once it has frozen.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

w

The  temperature  range  set  for  the  normal  mode  shines  in

the temperature display.*

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.6 Drawers

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.7 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

Control

5
