The appliance at a glance

Defrost drain

* Depending on model and options

Adjustable door racks*

Egg tray*

 Ice-cube tray*

Vegetable, salad and fruit bins

Butter stop

Adjustable storage shelves

On/off and temperature control, interior light

Description of appliance and equipment

fig.

 A

Controls,

fig.

 A1:

1

On/off

and

 temperature control

  "1" = warm

"7" = cold

  We recommend a

medium

 setting.

2

Cool-Plus switch

*

.  Switch on at low room temperatures of

18°C or below.

Interior light

Bulb data:

 max. 15 W, voltage and current should agree with the

details on the type plate, bulb fitting: E 14.

Replacing the bulb, fig.

A1a:

 Switch off the appliance.

W

Pull out the plug or switch off/unscrew the fuse.

W

  By moving the

bottle and can holder

, you can prevent bottles

from tipping over when the door is opened and closed. The holder

can be removed for cleaning:

-   fig.

A2

: The holder slides and releases left or right along the door

stops.

W

  You can remove all

door racks

 for cleaning, fig.

A2

: lift rack and

pull forwards.

W

  Shelves*

 can be adjusted in height for different height items, figs.

A4

:

-  Lift the shelf, slide forwards and remove.

-  Always insert shelves with the raised edge at the back pointing

upwards, otherwise food may freeze onto the rear wall.

W

  Removing drawers:

 Pull forward until the drawer stops

and lift out, fig.

 A3.

W

  Fig.

A5

: If you need space for large bottles and containers, then

simply push the front half of glass shelf

1

 back. For cleaning, the

holder

2

 can be used to remove the half glass shelves.

Refrigerator, approx. 5°C

Door rack for large bottles

Type/Data plate

Freezer, approx. -18°C

 Adjustable-height feet at front, transport castors at back

High drawers,

information system*

Adjustable bottle and can holder

Bottle shelf

Coldest zone of the refrigerator compartment, for sensitive

and perishable foodstuffs
