14

Making ice-cubes

W

Fill the

ice-cube tray

* three-quar-

ters full with water and freeze. The

ice-cubes can be removed from the

tray by twisting or by holding upside

down for a short time under running

water.

SuperFrost

The

fresh

 foods should be frozen to the core as quickly as

possible and frozen foods already stored be given a "cold

reserve". This is enabled by the SuperFrost

system. This is the best way of maintaining the nutritional

value, appearance and flavour of frozen foods.

W

  The maximum amount of fresh food which can be frozen

in 24 hours is shown on the rating plate ("Freezing capac-

ity ... kg/24h"), fig.

A4

,

pos.

4

. The maximum quantity of

frozen food varies according to model and climatic class.

Freezing with SuperFrost

Fig.

A1

/

5

You do

not

 have to switch SuperFrost on:

-  when inserting already frozen foods,

-  when freezing up to approx. 2 kg of fresh food daily.

W

  Press SuperFrost button

5

 briefly, so that the LED lights

up.

-  The freezing temperature decreases, the appliance works

with the greatest possible freezing capacity.

W

  With a smaller amount of food to be frozen, wait/pre-

freeze for approx 6 hours - normally sufficient, with the

maximum

 quantity, see freezing capacity on rating plate,

approx. 24 hours.

W

  Then insert the fresh food.

-    The SuperFrost function can be quit manually by briefly

pressing button

5

, if not:

-  SuperFrost switches off

automatically

 after approximately

65 hours.

-   the SuperFrost button is dark

-    the temperature range set for normal mode lights up in

the temperature display.

-    the appliance continues in normal energy-saving mode.

W

 In order to reach the maximum freezer performance,

warm food must be placed directly on the shelves, not in

the drawers, or stored in direct contact to the inner side

walls.

4 Refrigerator compartment

Arrangement of food

Due to the natural air circulation in the refrigerator com-

partment, different temperature ranges result, which are

beneficial for the storage of different foods. Just above the

vegetable bins and at the back of the refrigerator, the air is

colder, ideal for raw meat or cold meats; at the top front of

the compartment and in the door, the air is warmer, making

it ideal for cheese and for spreadable butter.

Notes on refrigerating

-  Store food so that the air can circulate freely; do not place

items too close together.

Do not cover the v

entilator air

slots*

on the rear wall

 - improtant for refrigerating capacity!

-  Always keep foods which easily give off or take on odours

or flavours, and liquids, in closed containers or covered.

 -  Always store food which gives off or is sensitive to eth-

ylene gases such as fruit, vegetables and salads sepa-

rately or wrapped in order not to affect their storage life;

e.g. do not store tomatoes together with kiwis or cabbage.

Changing the interior lighting

Light-bulb specifications:

max. 25 W

Socket: E 14

The current and voltage types should agree with the

information on the type plate

W

  Switch off the appliance.

Remove the mains plug, or trigger

or remove the fuse.

W

  Hold the lamp cover at the front according to the illustration,

and detach at the rear.

W

  Replace the bulb.

W

Re-install the cover.

5 Freezer compartment

*

 depending on model and options
