10

1 The appliance at a glance

*

 depending on model and options

Butter stop

Interior light

Egg tray*

Adjustable storage shelves

Defrost drain

Vegetable, salad and fruit bins

Door rack for large bottles

Freezer compartment, approx. -18

0

C

Rating plate

High drawers

Ice-cube tray*

Adjustable-height feet at front, transport castors at back

Description of appliance and equipment,

fig.

 A

Adjustable door racks*

W

By moving the

bottle and can holder

, you can prevent bot-

tles from tipping over when the door is opened and closed. The

holder can be removed for cleaning:

-   fig.

A2

: The holder slides and releases left or right along the door

stops.

W

  You can remove all

door racks

 for cleaning, fig.

A2

: lift rack and

pull forwards.

W

The shelves

* can be adjusted according to height of frozen

food, fig.

A4

.

-  Lift the shelf, slide forwards and remove.

-  Always insert shelves with the raised edge at the back pointing

upwards, otherwise food may freeze onto the rear wall.

W

Removing drawers:

Pull forward until the drawer stops and lift

out, fig.

 A3.

W

  Fig.

A5

: If you need space for large bottles and containers, then

simply push the front half of glass shelf

1

back. For cleaning,

the holder

2

 can be used to remove the half glass shelves.

Rating plate specifications

1

Appliance designation

2

  Service number

3

  Appliance number

4

Freezing capacity ... kg/24hrs.

Coldest zone of the refrigerator compartment, for sensitive

and perishable foodstuffs

Information system*

VarioSpace*

Operating controls

Operating controls,

fig.

 A1

1

Main on/off control for the complete appliance (refrigerator and freezer

compartment), with temperature control for freezer compartment

2

SuperFrost button with LED display for activated function - for

rapid freezing of fresh food

3

Temperature setting display for freezing temperature

4

Audible warning on/off button, with LED display for too high

temperature in freezer compartment

5

On/off switch and temperature control for refrigerator compartment

6

 Temperature setting display for refrigerating temperature

Recommended temperature settings:

-  Refrigerator compartment: Temperature setting display

6

:

5 °C

-  Freezer compartment: Temperature setting display

3

:

-18 °C

Fan with switch

7

, for increased air circulation

Refrigerator compartment, approx. 5

0

C

Adjustable bottle and can holder

Bottle shelf
