28

D

E

D734

If the appliance is to be fitted laterally to the kitchen
unit, it will be sufficient to loosen the screws of the
little plates (D), move them as shown in Fig. and
then fasten them up again. Fit the cover (E).

After having reversed the opening direction of
the doors check that all the screws are properly
tightened and that the magnetic seal adheres to
the cabinet. If the ambient temperature is cold
(i.e. in Winter), the gasket may not fit perfectly to
the cabinet. In that case, wait for the natural
fitting of the gasket or accelerate this process by
heating up the part involved with a normal
hairdrier.

PR167/1

Hd

Hb

Fix cover (Hd) on guide (Hb) until it clips into place.

PR168

Hb

Place the small square on the guide again and fix it
with the screws supplied.

Should the lining up of the furniture door be
necessary, use the clearance of slots.

At the end of operations, it is necessary to check if
the door of the furniture closes properly.
