EN-3

Description

1.  Freezer light

2.  Movable ice maker

<Only for SJ-XG55PM>

3.  Freezer shelf (Upper)

4.  Freezer shelf (Bottom)

5.  Freezer case

Move the partition to fit the

size of food.

6.  Two-way fresh room door

7.  Fresh shelf

8.  Deodorizing unit

Deodorizing catalyst is installed on the routes of cold

air. There is no need to operate and clean.

9.  Refrigerator light

10.  Refrigerator shelf

11.  Hybrid cooling panel

The panel cools the refrigerator compartment

indirectly from the rear. In this way, food is cooled

gently without being exposed to cold air flow.

12.  Fruit and vegetable shelf

13.  Fruit and vegetable crisper

14.  Adjustable foot

15.  Magnetic door seal

16.  Control panel

17.  Freezer door pocket

18.  In-door ice maker

<Only for SJ-XG60PG,

SJ-XG60PM>

(This ice maker is packed inside the freezer

compartment. Refer to the next page ”After cleaning“

to install.)

19.  Water cup

<Only for SJ-XG60PG,SJ-XG60PM>

(The water cup is packed inside the freezer case.

Make sure to put the cup on the position indicated in

the picture above to use.)

20.  Egg pocket

21.  Refrigerator pocket (Upper)

22.  Bottle pocket

23.  Refrigerator pocket (Bottom)

If you wish to store large items within

your refrigerator

• You may remove any shelves or any pockets numbered

2,3,5,6,7,10,13,17, 18, 19, 20, 21, 22, 23 in the picture

above.

•

Cooling performance is not influenced even if you use

the refrigerator in the above situation.

Partition

Freezer case

Partition

Freezer case

Use the space as

refrigerator room.

Use the space as

fresh room.

Two-way fresh room door

How to open the two-way fresh room door

1) Lift up the door.

2) Insert the door into the frame

    and push it back to the stopper.

    It is locked properly.

Open

Close

Open

Close

Two-way fresh room door

1. Freezer light
2. Movable ice maker

<Only for SJ-XG55PM>

3. Freezer shelf (Upper)

4. Freezer shelf (Bottom)

5. Freezer case

size of food.

6. Two-way fresh room door

7. Fresh shelf

8. Deodorizing unit

Deodorizing catalyst is installed on the routes of

cold air. There is no need to operate and clean.

9. Refrigerator light

10. Refrigerator shelf

11. Hybrid cooling panel

The panel cools the refrigerator compartment

indirectly from the rear. In this way, food is cooled

gently without being exposed to cold air  ow.

12. Fruit and vegetable shelf

13. Fruit and vegetable crisper

14. Adjustable foot

15. Magnetic door seal

16. Control panel

17. Freezer door pocket

18. In-door ice maker

<Only for SJ-XG60PG,

(This ice maker is packed inside the freezer

compartment. Refer to the next page ”After

cleaning“ to install.)

19. Water cup

<Only for SJ-XG60PG,SJ-XG60PM>

(The water cup is packed inside the freezer case.

Make sure to put the cup on the position indicated

in the picture above to use.)

20. Egg pocket

21. Refrigerator pocket (Upper)

22. Bottle pocket

23. Refrigerator pocket (Bottom)

If you wish to store large items within your

refrigerator

• You may remove any shelves or any pockets numbered

2,3,5,6,7,10,13,17, 18, 19, 20, 21, 22, 23 in the picture

above.

•

refrigerator in the above situation.

Use the space as

refrigerator room.

Use the space as

fresh room.

How to open the two-way fresh room door

1) Lift up the door.

2)  Insert the door into the frame and

push it back to the stopper. It is

locked properly.

Open

Close

        SJ-XG740G,SJ-XG740M

1

3

4

5

7

6

8

9

11

14

14

13

15

19
18

15

16

20

22

23

12

10

1

3

4

2

5

7

6

8

9

11

14

14

13

15

15

17
16

20

22

23

12

10

21

21

17

Partition

Freezer case

Partition

Freezer case

Open

Close

SJ-XG60PG,SJ-XG60PM

SJ-XG55PM

SJ-XG60PM>
