Care and Maintenance

55

1

2

1

3

4

• To Remove the shelf from refrigerator, at first – lift up it (1),

   and then – pull it out side (2). In case of wrong removing

   of the shelf, the damages of inner surfaces of refrigerator

   possible.

• To install shelf into refrigerator follow similar: lift up

   front side of the shelf at the angle (3) and then insert

   it inside (4). In case of wrong installing of the shelf,

   the damages of inner surfaces of refrigerator possible.

Remove/Install

shelf

Lamp

Replacement

1. Unplug the power cord from the outlet.

2. Remove fridge shelves.

3. To remove the lamp cover, insert type

    driver in the underside of the lamp

    cover and pull it out forwards.

4. Turn the lamp counterclockwise.

5. Install the new bulb and put the cover back.

    The new lamp should have same

    characteristics as replaced one.

6. MAXIMUM rated input of lamp should

    not to exceed 20 W.

Warning
