16

WATER SUPPLY KIT

※

   Check the parts below for installing water supply.

Necessary parts are available at your local service

agents.

Connector

Water tube

Filter Box

Installation Procedure

1. Join connector to the tap water line

Figure A

Connector

Water tube

Filter Box

Figure B

Place the rubber washer inside the tap connector

and screw onto the water tap.

2. Connect the Water Tube to the refrigerator.

1)  Remove the rear cover at the bottom back of the

refrigerator.

2)  Insert the fastening ring into the Water tube. (Be careful

to follow the direction of the nut.)

3)  Insert the Water Tube into the top of the Water Valve,

turn the nut clockwise to fasten it. (The Water valve is to

the right of the motors.)

4)  Check for any bent tubes or water leaks; if so, reckeck

installation procedure.

5)  Replace the rear cover. (The Water Tube should be

placed between the groove of the refrigerator back and

motor cover.)

※

Set the tube upright as the figure shows.

3. After installation of Water Supply System

1)  Plug in the refrigerator, press the [WATER] button on the

control panel for 2~3 minutes to remove any air (bubble)

in the pipes and drain out the initial water.

2)  Check for the water leaks again through the water supply

system(tubes, connectors and pipes). Rearrange the

tubes again and do not move the refrigerator.
