en

13

Vegetable container with

humidity control

Fig.

'

To create the optimum storage climate

for fruit and vegetables, you can set

the humidity level in the vegetable

container:

■

Mainly vegetables as well as for a

mixed or small load – high air

humidity

■

Mainly fruit as well as for a large load

– low air humidity

Notes

■

Fruit sensitive to cold (e.g. pineapple,

banana, papaya and citrus fruit) and

vegetables sensitive to cold (e.g.

aubergines, cucumbers, zucchini,

peppers, tomatoes and potatoes)

should be stored outside

the refrigerator at temperatures

of approx. +8 °C to +12 °C for

optimum preservation of quality and

flavour.

■

Condensation may form in the

vegetable container depending on the

type and quantity of products stored.

Remove condensation with a dry cloth

and adjust air humidity in the

vegetable container with the humidity

controller.

Cold storage compartment

Fig.

&

The cold storage compartment has lower

temperatures than the refrigerator

compartment. Even temperatures below

0 °C may occur.
Ideal for storing fish, meat and sausage.

Not suitable for lettuce and vegetables

and produce sensitive to cold.

The temperature of the chill

compartments can be varied using the

ventilation opening. Push temperature

controller upwards to reduce the

temperature. Push temperature controller

downwards to increase the temperature.

Fig.

&

Super cooling

Super cooling sets the refrigerator

temperature to the coldest temperature

setting for approx. 6 hours. Then

the appliance automatically switches

to the temperature set prior to super

cooling mode.
Switch on super cooling mode, e.g.

■

before placing large quantities of food

in the refrigerator compartment.

■

for the fast cooling of drinks.

Switching on and off

Fig.

"

1. Select the fridge compartment using

the fridge button.

2. Press the temperature setting button 6

repeatedly until the super display is lit.

You do not need to switch off the super

cooling. After 6 hours, the previously set

temperature is automatically restored.
