InstructIon MAnuAl

bArbecue

plEasE rEad this instruction

carEFullY BEForE usE and rEtain

For FuturE rEFErEncE

caution! the unit is only intended for

indoor use and not for outdoor use.

normal use

•  The unit is only intended for grilling

suitable food.

•  No other use is permitted! any liability or

guarantee will cease to apply in the event

of damage caused by incorrect operation,

incorrect use and not observing the safety

regulations.

sAFety reGulAtIons

•  Be careful when you use the unit

•  Only connect the unit to an altemating

current supply as per the type plate.

•  Do not allow the unit or cable to come into

contact with extremely hot surfaces.

•  Do not use the cable rolled up. (this also

applies to any extension cable used)

•  The socket must be easily accessible at

any time to ensure that the unit can be

disconnected quickly from the electricity

supply.

•  Check the power cable and the unit

regularly for damage.

•  Do not use the unit again if the power

cable shows signs of damage or if the unit

is itself.

•  Danger of injury if necessary remove the

plug carefully and contact your specialist

dealer or customer service.

•  The unit should be fitted with an RCD and

operated with a nominal residual current

of no more than 30ma. ask your electrical

installer.

•  Do not store or use any easily inflammble

materials or sprays near the unit when it

is in use danger of fire.

•  Do not use the unit in easily combustible

atmospheres (e.g near inflammable gases

or spray cans).

•  danger of explosion and fire do not use

the unit in rooms with baths,showers or

swimming pools or near wash basins or

taps.

•  Do not expose the unit to rain or other

damp conditions.

•  Children or people under the influence

of drugs or alcohol may only use the unit

under supervision.

•  ensure that children do not have the

opportunity to play with electrical

equipment.

•  Leave the unit to cool down after use

before you pick it up and put it away.

•  Never put plastic parts or any other items

except for the food to be grilled on the grill

rack.

•  Watch out of for fat splashing when

grilling meat. risk of burns

•  Do not use any plastic cutlery to put the

food on the grill rack,turn it or remove it.

•  The unit must never be used under a

running extractor fan or wall cupboards

•   Never cover the grill rack completely

when it is operating,e.g. with aluminium

foil because otherwise the heat cannot be

dissipated

•  This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge.

Unless they have been given supervision

or instruction concerning use of the

appliances by a person responsible for

their safety.

•  If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified persons in

order to avoid a hazard.

•  Do not operate with an external timer or

remote-control device.

rIsK oF overheAtInG

caution! The grill rack, heating element and

housing get very hot when in use. Therefore

put the unit somewhere where it can’t be

touched accidentally.

caution! Never use charcoal or similar fuels

on the electric grill.
•  Do not touch the grill rack and heating

element.

•  Only use the unit when the aluminium

reflector is immersed in water.

•  The operating instructions belong to the

unit and must be handed over too if the

unit is passed on.

•  Do not use any accessories that are not

expressly approved by the manufacturer.

specIAl sAFety hInts

•  ensure that the thermostat is inserted

correctly into the base. Otherwise the

unit cannot be used. The thermostat is

fitted with a safety switch. The heating

element switches off automatically if the

thermostat is removed from the unit. Do

not touch the heating element when it is

on. It gets extremely hot.

•  WArnInG: Charcoal or similar

combustible fuels must not be used with

this appliance.

•  Minimum quantity of water to be poured

into the appliance is 1.1l.

•  Maximum quantity of water to be poured

into the appliance is 1.4l.

AsseMblInG the unIt

First of all unpack everything and refer

to the illustrations for installation. Fit the

heating element. ensure that the safety

switch is fitted to the edge of the base. Fit

the blower, insert it into the base as shown

in the illustration. Fit the aluminium grill rack

over the heating element. attach the four

feet one after the other under the base by

turning them clockwise. Tighten the screws

also please follow figures 1-8 instruction to

assemble the product accordingly.
step 1

Tighten support shelf (part 16) and feet (part

17) with M5 screws (pic. 1)
step 2

put pillar of part 4 (upper handle) correct into

holes of part 7 (pan). Tighten part 4 (upper

handle) with part 6 (lower handle) with screws

as shown on picture 2.
step 3

Connet step 1 and 2 with part 9. (pic. 3, 4)
step 4 (pic. 5, 6)

Insert the reflecting plane. put the control

box (pic. 5a) (including heating element) to

the foreseen spot (compare with picture from

step 3). Feet of heating elements put into the

right holes.
step 5

put support shelf centrally and put its feet

into the foreseen square-holes (as shown on

picture 7).
caution! never use the unit without

water in the base tray. the water level

must be between the MIn & MAX marks.

operAtIon

Water has to be on the aluminum reflector.

•  Switch the unit on and set the required

temperature with the thermostat knob.

To do this turn the (“MIN/MaX”) knob

clockwise the unit heats up automatically

to the set temperature and then it turns

the heating off!

•  The control light comes on while it is

heating up. Should the temperature fall

below the set temperature the the unit

starts to heat up again. Thus a constant

temperature is maintained.

•  The grill rack can be placed at various

heights to ensure the optimum distance

between the food and the heating

element.

•  power consumption depends on the

thermostat setting. For lengthy grilling it is

advisable to set the temperature as high

as possible.

•  When you finish grilling turn the

thermostat knob to “MIN’ the unit will

now cool down. Take the plug out of the

socket.

•  The cooling process will take some time.

Do not move the unit until it has cooled

down.

•  please hold onto the supporting feet when

transporting the whole grill because the

grill and base are not firmly fixed to each

other.

Grilling

This unit can be used to grill sausages, meat,

fish etc. Don´t use materials like charcoal or

wood for grilling. Do not cover the grill rack

with film (aluminium foil or transparent film for

example).

cleAnInG

1.  Before cleaning remove the plug from the

socket and let the unit cool down.

2.  Remove the heating element from the

base.

3.  Then remove the base, the outer heat

retaining cover and the grill rack. Do not

use any cleaning agents. Do not clean the

unit with scourers to avoid scratching it.

•  neVer immerse the plug, the power

cable, the heating element or the

thermostat in liquids. these parts must

only be wiped over with a dry cloth.

4.  The grill rack can be cleaned with a soft

brush.
