EN - 3

The operator is able to operate the machine and use the 

main controls, always staying behind the handle at a safe 

distance from the rotating cutting means.

If the operator leaves the machine, the motor and cutting 

means will stop within a few seconds.

Intended use

This machine is designed and built to cut (and collect) grass 

in gardens and grassy areas, with a height according to its 

cutting capacity, driven by an operator walking behind it.
Generally speaking this machine can:

1.

Mow the grass and collect it in the grass catcher bag.

2.

Mow the grass and discharge it on the ground through 

the rear part (if available).

3.

Mow the grass and discharge it on the ground laterally 

(if available).

4.

Mow the grass, chop it and discharge it on the ground 

(mulching effect - if available).

The use of special attachments provided for by the Manu

-

facturer as original equipment or which may be purchased 

separately, allows this work to be done in various operating 

modes, illustrated in this manual or the instructions that 

accompany the single attachments.

 3.1.1

Improper use

Any other usage, different than the afore-mentioned may be 

hazardous and harm persons and/or damage things.

Examples of improper use may include, but are not limited to:

•

Allowing children, animals or other passengers on the 

machine as they could fall off and injure themselves or 

compromise safe driving by the operator;

•

Letting oneself be transported by the machine;

•

Using the machine to tow or push loads;

•

Using the cutting means on surfaces other than grass;

•

Using the machine for leaf or debris collection;

•

Using the machine to trim hedges, or for cutting vegeta

-

tion other than grass;

•

using of the machine by more than one person.

IMPORTANT

Improper use of the machine will in-

validate the warranty, relieve the Manufacturer from all

liabilities, and the user will consequently be liable for all

and any damage or injury to himself or others.

 3.1.2

User types

This machine is intended for use by consumers, i.e. 

non-professional operators.

It is intended for "DIY" use only.

IMPORTANT

 The machine must be used by one

operator.

 3.2  SAFETY SIGNS

The machine has various symbols on it (Fig.2.0). Their func

-

tion is to remind the operator of the correct conduct for use, 

with due care and caution. Meanings of the symbols:

Warning.

Read the instructions before

operating the machine

Warning!Do not put hands or feet inside

the compartment of the cutting means. 

Remove the spark plug cap and read the 

instructions before carrying out any main

-

tenance or repair work.
Danger! Risk of thrown objects.

Keep all

persons away from the work area whilst 

working.

Danger! Danger of cutting.

Cutting

means in motion.  Do not put hands or in

-

side the housing of the cutting means.

IMPORTANT

Any damaged or illegible decals must

be replaced. Order replacement decals from an Author-

ised Service Centre.

 3.3  IDENTIFICATION LABEL

The identification label holds the following data (Fig.1.0).

1.

Sound power level.

2.

CE conformity marking.

3.

Year of manufacture.

4.

Type of machine.

5.

Serial number.

6.

Name and address of Manufacturer.

7.

Article code.

8.

Nominal power and maximum operating engine speed.

9.

Weight in kg.

Write the identification data of the machine in the specific 

space on the label on the back of the cover page.

IMPORTANT

 Quote the information on the product

identification label whenever you contact an Authorised

Service Centre.

IMPORTANT

The example of the Declaration of Con-

formity is provided on the last pages of the manual.

 3.4  MAIN COMPONENTS

(Fig.1)

A.

Chassis.

B.

Engine.

C.

Cutting means.

D.

Rear discharge guard.

E.

Side discharge guard (if equipped).

F.

Side discharge chute (if equipped).

G.

Grass catcher.

H.

Handle.

I.

Engine brake lever / cutting means.

J.

Drive engagement lever.

 Strictly observe the indications and the safety regu-

lations described in chap. 2..

4.  ASSEMBLY

Certain components of the machine are not installed in the 

factory and have to be assembled after unpacking, follow

-

ing the instructions below.

Unpacking and completing the assembly should be

done on a flat and stable surface, with enough space for

moving the machine and its packaging.

.

Do not use the

machine until all the instructions provided in the “AS-

SEMBLY” section have been carried out.

 4.1  UNPACKING

(

F

ig.3.0)

1.

Remove all the unassembled parts from the box.

2.

Take out the machine 

and dispose of the box and 

packaging in compliance with local regulations.

 4.2  HANDLE ASSEMBLY

(Fig.4.A/B/C)

 4.3  GRASS CATCHER ASSEMBLY

(Fig.5,6,7)

 4.4  CONNECTING THE BATTERY

•

Models with push-button electric start

: 

refer to the owner's manual of the engine.
