14

Lawnmower Model LM400

Assembly

Battery Pack and Charger

Operation (Fig. G)

First, make sure you are in the proper cutting

area  Ensure the cutting area is free of bystanders

and foreign objects  Inspect the machine for any

possible damage or unsafe conditions

Ensure the cutting height of the machine is at your

desired height

Ensure the safety key points toward one battery

position

Press and hold the safety button

(1)

, squeeze the

switch lever

(2)

 towards the handlebar

(Fig. G)

When the unit starts, release the safety button

(1)

  Maintain squeezing the switch lever with two

hands during use

Releasing the switch lever will disengage power

to the unit  The blades may continue to rotate for

a period of time after power is disengaged

Stopping the Machine (Fig. H)

Release the switch lever

(1) (Fig. H)

  Releasing

the switch lever will disengage power to the unit

The blades may continue to rotate for a period of

time after power is disengaged

Using Rear Bagging (Fig. I - J)

Assemble the debris bag by inserting the metal

frame into the soft mesh bag

(1)

 and connecting

the plastic clips from the soft mesh bag to the

metal frame

(2) (Fig. I)

To attach the debris bag to the machine, lift and

hold the discharge cover

(1)

 with one hand, and

with the opposite hand, place the two hooks

(2)

from the debris bag onto the metal shaft

(3)

on

each side of the discharge cover

(Fig. J)

  Release

the spring loaded discharge cover, allowing the

cover to collapse over the opening between the

debris bag and the machine

Using the Side Discharge (Fig. K)

First, take the debris bag off  In a slight downward

angle, position the front and rear hooks of the

discharge chute onto the metal pin of the side

cover

(1) (Fig. K)

  Rotate the chute down causing

the hooks to lock in place

(2)

  Release the side

cover with your hand, check the chute is properly

in place

Using the Mulching Plug (Fig. L)

Lift the discharge cover and remove the debris

bag

(1) (Fig. L)

  Hold the discharge cover with

one hand, and with the opposite hand, place the

mulching plug in the rear discharge chute

(2)

Release the spring loaded discharge cover

Replacing or Sharpening

the Cutting Blade

 WARNING: Always remove the battery

and the safety key when performing any

maintenance.

The cutting blade is designed to be a replacement

item and may need sharpening from time to time

Sharpen when dull  Replace when damaged

Contact your dealer or the manufacturer for proper

instructions

Storage (Fig. M - N)

Pull and twist the knob on the left side of the unit,

so that the knob rests on the handle

(1)

  On the

opposite side , with one hand pull the knob

(2)

 and

with the other hand pull down the handle to the

front of the lawnmower

(3)

(Fig. L)

  Then, lift the

machine from the front until it rests safely on the

rear frame of the machine

(Fig. M)
