To stop the drive (model LC 141VLi)

To stop the drive but keep the motor running, release

only the propulsion bar.

To stop the motor

1. Stop the motor by releasing the motor brake handle.

2. Hold down the ON/OFF button (1) on the panel until

the green LED (2) goes out.

The product will be turned off automatically if inactive

for 10 minutes. Never leave the product unattended

when the safety key is in position ”1”.

3. Open the protective cover and turn the safety key to

position ”0”.

4. Recharge the battery if weak. For more information,

see

To charge the battery on page 113.

5. Remove the battery from the product by pressing the

two release buttons and pulling out the battery.

To start and stop cord powered mower

(model LC 141C)

Before starting:
• Keep people and animals well away from the

working area.

• Perform daily maintenance. See instructions in the

section

 Maintenance schedule on page 116.

To select an approved cable (LC 141C)

If extension cables are used, these must comply with the

minimum cross-sections in the table below:

Voltage

Cable length

Cross section

220-240V/ 50Hz Up to 20 m

1.5 mm

2

220-240V/ 50Hz 20–50 m

2.5 mm

2

• Mains cables and extension cables are available

from your local approved service agent for

Husqvarna outdoor products.

• Only use extension cables specifically designed for

outdoor use and which conform to one of the

following specifications: Ordinary rubber (60245 IEC

53), Ordinary PVC (60227 IEC 53) or Ordinary PCP

(60245 IEC 57)

• If the cable is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

To start

1. Connect a power cord to the socket below the

handle.

71 - 001 - 03.11.2016

115
