en

Startup

18

Rasentrimmer GTLi 18V

3. The charging process has finished when the

LED  on  the  mains  adapter  lights  up  green  -

the battery is fully charged.

4. Disconnect the charger from the mains.
5. Remove the battery from the charger.

Inserting the battery

1. Press the locking catch.
2. Push the battery along the guide until the con-

tact socket on the battery is firmly located on

the contact plug of the appliance.

Adjusting the telescopic handle

1. To  release,  turn  the  upper  locking  sleeve

through about 180° to the right (4-1).

2. Set  the  telescopic  handle  to  the  individual

physique.  The  telescopic  handle  can  be  ex-

tended by approx. 10 cm (4-2).

3. Tighten the locking sleeve (4-3).

Swivelling the cutter head

To trim lawn edges, for example, it is possible to

swivel the cutter head through 180° (5, 6).
1. Loosen the lower locking sleeve (5-1).
2. Turn the telescopic handle through 180° (5-2).
3. Screw the locking sleeve tight (5-3, 6-1).

Angling the cutter head

By changing the pivot angle, it is also possible to

trim  areas  that  are  difficult  to  access,  e.g.  under

benches, overhangs, etc.
1. Press the locking button (7-1).
2. Engage the cutter head in the required angle

(7-2).

3. Release the locking button.

ADVICE

Remove the guard on the line cutter be-

fore  taking  into  operation  for  the  first

time.

Starting the lawn trimmer

1. Stand securely.
2. Hold  the  appliance  with  both  hands.  Do  not

place the cutter head on the ground when do-

ing this.

3. Hold the auxiliary handle in one hand and the

upper grip with your other hand.

4. Press the switch in the upper grip and hold it

pressed. The appliance runs.

5. Let the lawn trimmer run at idling speed for a

few moments. This causes the cutting line to

be cut off to the correct length.

6. The appliance switches off when the switch is

released.

ADVICE

After  the  appliance  has  been  switched

off, the spool head continues to rotate for

a few seconds.

OPERATION

Switch on the appliance before approaching

the grass to be cut.
Angle  the  appliance  forwards  slightly,  and

walk forwards slowly (9).
Sweep  the  appliance  to  the  right  and  left  in

order to cut the grass (9).

Long grass must be cut in several passes. Always

proceed from top (10-1, 10-2) to bottom.

ADVICE

Tap the spool head on the ground from

time to time when working. The automa-

tic  tip  function  always  keeps  the  line  at

optimum length.

Use the plant protection car in order to hold

the  appliance  at  the  correct  distance  from

obstacles (11-1).

Do not overload the appliance during work.

Make  sure  the  motor  is  stopped  before  you

remove any cuttings.

CAUTION!

The  vibration  value  during  use  of  the

electrical implement may differ from the

indicated  value,  depending  on  what  the

appliance is used for.

If  the  battery  lawn  trimmer  is  overloaded  in

very long grass, the line will be blocked. Im-

mediately remove the appliance from the long

grass  and  reduce  the  load.  Otherwise,  the

motor could be permanently damaged.

After use, remove the battery and check the app-

liance for damage.

MAINTENANCE AND CARE

CAUTION!

Remove  the  battery  before  starting  any

work on the appliance.

After use, remove the battery and check the

machine for damage.
Electrical malfunctions are only allowed to be

rectified by authorised specialist workshops.
Never  use  the  appliance  if  the  blade  of  the

line cutter is missing or damaged.
