7

ENGLISH

Reversing switch action

1

A

B

►

1.

 Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the

direction of rotation before the tool stops may dam

-

age the tool.

CAUTION:

When not operating the tool,

always set the reversing switch lever to the neu-
tral position.

This tool has a reversing switch to change the direction
of rotation. Depress the reversing switch lever from the
A side for clockwise rotation or from the B side for coun-
terclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion, the switch trigger cannot be pulled.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed
before carrying out any work on the tool.

Selecting correct impact socket

Always use the correct size impact socket for bolts and

nuts. An incorrect size impact socket will result in inac-
curate and inconsistent fastening torque and/or damage
to the bolt or nut.

Installing or removing impact socket

1

2

►

1.

 Impact socket

2.

 Square drive

To install the impact socket, push it onto the square
drive of the tool until it locks into place.

To remove the impact socket, simply pull it off.

Installing hook

CAUTION:

When installing the hook, always

secure it with the screw firmly.

 If not, the hook

may come off from the tool and result in the personal

injury.

1

2

3

►

1.

 Groove

2.

 Hook

3.

 Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install
the hook, insert it into a groove in the tool housing on
either side and then secure it with a screw. To remove,
loosen the screw and then take it out.
