11 ENGLISH

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Selecting correct impact socket

Always use the correct size impact socket for bolts and

nuts. An incorrect size impact socket will result in inac-

curate and inconsistent fastening torque and/or damage

to the bolt or nut.

Installing or removing impact socket

Optional accessory

CAUTION:

Make sure that the impact socket

and the mounting portion are not damaged before

installing the impact socket.

CAUTION:

After inserting the impact socket,

make sure that it is firmly secured. If it comes out,

do not use it.

NOTE:

 The way of impact socket installation varies

depending on the type of the square drive on the tool.

Tool with the ring spring

Model TW007G

For impact socket without O-ring and pin

►

Fig.10:

1.

 Impact socket

2.

 Square drive

3.

 Ring

spring

Push the impact socket onto the square drive until it

locks into place.

To remove the impact socket, simply pull it off.

For impact socket with O-ring and pin

►

Fig.11:

1.

 Impact socket

2.

 O-ring

3.

 Pin

Move the O-ring out of the groove in the impact socket

and remove the pin from the impact socket. Fit the

impact socket onto the square drive so that the hole in

the impact socket is aligned with the hole in the square

drive.

Insert the pin through the hole in the impact socket and

square drive. Then return the O-ring to the original posi-

tion in the impact socket groove to retain the pin.
To remove the impact socket, follow the installation

procedures in reverse.

Tool with the detent pin

Model TW008G

For tool with light fit detent pin

►

Fig.12:

1.

 Impact socket

2.

 Hole

3.

 Square drive

4.

 Detent pin

To install the socket, align the hole in the side of the

socket with the detent pin on the square drive, and then,

push it onto the square drive until it locks into place. Tap

it lightly if required.

To remove the socket, simply pull it off.

For tool with firm fit detent pin

Optional accessory

►

Fig.13:

1.

 Impact socket

2.

 Hole

3.

 Square drive

4.

 Detent pin

To install the socket, align the hole in the side of the socket with

the detent pin on the square drive, and then, push it onto the

square drive until it locks into place. Tap it lightly if required.

To remove the socket, depress the detent pin through the

hole in the socket and pull the socket off the square drive.

NOTE:

 The firm fit detent pin may fit too securely to

remove the socket.

In that case, depress the firm fit detent pin fully and

pull the socket off the square drive.

Installing hook

CAUTION:

When installing the hook, always

secure it with the screw firmly.

 If not, the hook

may come off from the tool and result in the personal

injury.

►

Fig.14:

1.

 Groove

2.

 Hook

3.

 Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

Ring

Country specific

CAUTION:

Before using the ring, always

make sure that the bracket and ring are secured

and not damaged.

CAUTION:

Use the hanging/mounting parts

for their intended purposes only.

 Using for unin-

tended purpose may cause accident or personal

injury.

►

Fig.15:

1.

 Bracket

2.

 Ring

3.

 Screws

The ring is convenient for hanging the tool with hoist.

First, place the rope through the ring. Then hang the

tool up to the air with hoist.

OPERATION

CAUTION:

Always insert the battery cartridge

all the way until it locks in place.

 If you can see the

red indicator, it is not locked completely. Insert it fully

until the red indicator cannot be seen. If not, it may

accidentally fall out of the tool, causing injury to you

or someone around you.

►

Fig.16

Hold the tool firmly and place the impact socket over the bolt or

nut. Turn the tool on and fasten for the proper fastening time.

The proper fastening torque may differ depending upon

the kind or size of the bolt, the material of the workpiece

to be fastened, etc. The relation between fastening

torque and fastening time is shown in the figures.
