7 ENGLISH

Lighting up the front lamp

CAUTION:

Do not look in the light or see the

source of light directly.

►

Fig.5:

1.

 Lamp

►

Fig.6:

1.

 Button

Pull the switch trigger to turn on the lamp. To turn off,

release it. The lamp goes out approximately 10 seconds

after releasing the switch trigger.
To keep the lamp off, turn off the lamp status. First pull

and release the switch trigger. And then press the but-
ton

 for one second within 10 seconds.

To turn on the lamp status again, press the button again similarly.

NOTE:

To confirm the lamp status, pull the trigger. When the

lamp lights up by pulling the switch trigger, the lamp status is

ON. When the lamp does not come on, the lamp status is OFF.

NOTE:

 When the tool is overheated, the light flashes

for one minute, and then the LED display goes off. In

this case, cool down the tool before operating again.

NOTE:

 Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Reversing switch action

►

Fig.7:

1.

 Reversing switch lever

CAUTION:

Always check the direction of

rotation before operation.

CAUTION:

Use the reversing switch only after

the tool comes to a complete stop.

 Changing the

direction of rotation before the tool stops may dam

-

age the tool.

CAUTION:

When not operating the tool,

always set the reversing switch lever to the neu-

tral position.

This tool has a reversing switch to change the direction

of rotation. Depress the reversing switch lever from the

A side for clockwise rotation or from the B side for coun-

terclockwise rotation.

When the reversing switch lever is in the neutral posi-

tion, the switch trigger cannot be pulled.

Changing the impact force

►

Fig.8:

1.

 Hard

2.

 Soft

3.

 Reverse rotation auto stop

mode

4.

 Changed in three steps

5.

 Button

You can change the impact force in three steps: hard,

soft, and Reverse rotation auto stop mode.

This allows a tightening suitable to the work.

Every time the button is pressed, the number of blows

changes in three steps.

The function of Reverse rotation auto stop mode works only with pulling the trigger fully in counterclockwise tool

rotation. When the bolt/nut gets enough loosened, the tool stops the impact and rotation.

For approximately one minute after releasing the switch trigger, the impact force can be changed.

Impact force grade displayed

on panel

Maximum blows

Purpose

Example of application

Hard

3,600 min

-1

 (/min)

Tightening when force and

speed are desired.

Assembling steel frames.

Soft

2,000 min

-1

 (/min)

Tightening when you need fine

adjustment with small diameter

bolt.

Assembling furniture.

Reverse rotation auto stop

mode

3,600 min

-1

 (/min)

Loosening with auto stop

function.

Disassembling bolts/nuts.

NOTE:

 Reverse rotation auto stop mode is available only when the tool rotates counterclockwise. When rotating

clockwise in Reverse rotation auto stop mode, the impact force and speed are the same as Hard impact mode.

NOTE:

 When all lamps on the switch panel go out, the tool is turned off to save the battery power. The impact force

grade can be checked by pulling the switch trigger to the extent that the tool does not operate.

NOTE:

 While pulling the switch trigger, the impact force grade cannot be changed.
