6 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery cartridge

firmly when installing or removing battery cartridge.

Failure to hold the tool and the battery cartridge firmly may

cause them to slip off your hands and result in damage to

the tool and battery cartridge and a personal injury.

►

Fig.1:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.

To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge fully

until the red indicator cannot be seen.

 If not, it may accidentally

fall out of the tool, causing injury to you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Indicating the remaining battery capacity

Only for battery cartridges with the indicator

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys

-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto

-

matically stop during operation if the tool or battery is

placed under one of the following conditions:

Overload protection

When the battery is operated in a manner that causes

it to draw an abnormally high current, the tool automat-

ically stops without any indication. In this situation, turn

the tool off and stop the application that caused the tool

to become overloaded. Then turn the tool on to restart.

Overheat protection

When the tool/battery is overheated, the tool stops

automatically. In this situation, let the tool/battery cool

before turning the tool on again.

Overdischarge protection

When the battery capacity is not enough, the tool stops

automatically. In this case, remove the battery from the

tool and charge the battery.

NOTE:

 Overheat protection (for battery) will work only

with batteries with star marking.

►

Fig.3:

1.

 Star marking

Switch action

►

Fig.4:

1.

 Switch trigger

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop.

NOTE:

 The tool automatically stops if you keep pull

-

ing the switch trigger for about 6 minutes.

Lighting up the front lamp

CAUTION:

Do not look in the light or see the

source of light directly.

►

Fig.5:

1.

 Lamp

►

Fig.6:

1.

 Button

Pull the switch trigger to turn on the lamp. To turn off,

release it. The lamp goes out approximately 10 seconds

after releasing the switch trigger.

To keep the lamp off, turn off the lamp status. To turn off the

lamp status, first pull and release the switch trigger. And

then press the button

 for one second within 10 seconds.

To turn on the lamp status again, press the button again

similarly.
