10

Trimmer guide

Trimming, curved cuts in veneers for furniture and the like
can be done easily with the trimmer guide. The guide
roller rides the curve and assures a fine cut.

(Fig. 20)

Loosen the wing bolts and secure the tool base horizon-
tally. Install the trimmer guide on the tool base with the
clamp screw (A). Loosen the clamp screw (B) and adjust
the distance between the bit and the trimmer guide by
turning the adjusting screw (1 mm per turn). At the
desired distance, tighten the clamp screw (B) to secure
the trimmer guide in place.

(Fig. 21)

When cutting, move the tool with the guide roller riding
the side of the workpiece.

(Fig. 22)

MAINTENANCE

CAUTION:
• Always be sure that the tool is switched off and

unplugged before carrying out any work on the tool.

Replacing carbon brushes

Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.

(Fig. 29)

Use a screwdriver to remove the brush holder caps. Take
out the worn carbon brushes, insert the new ones and
secure the brush holder caps.

(Fig. 30)

To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be per-
formed by Makita Authorized or Factory Service Centers
always using Makita replacement parts.

For European countries only

Noise and Vibration

ENG003-2

The typical A-weighted sound pressure level is 79 dB (A).
Uncer tainty is 3 dB (A).
The noise level under working may exceed 85 dB (A).

– Wear ear protection. –

The typical weighted root mean square acceleration value is
not more than 2.5 m/s

2

.

These values have been obtained according to EN60745.

EC-DECLARATION OF CONFORMITY

ENH101-4

We declare under our sole responsibility that this product
is in compliance with the following standards of standard-
ized documents,

EN60745, EN55014, EN61000

in accordance with Council Directives, 73/23/EEC,
89/336/EEC and 98/37/EC.

Yasuhiko Kanzaki

CE 2005

                Director

MAKITA INTERNATIONAL EUROPE LTD.

Michigan Drive, Tongwell, Milton Keynes,
Bucks MK15 8JD, ENGLAND

Responsible manufacturer:
Makita Corporation Anjo Aichi Japan
