13 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION:

•

Always be sure that the tool is switched off and

the battery cartridge is removed before adjust

-

ing or checking function on the tool.

Installing or removing battery cartridge

►

Fig.2:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

CAUTION:

•

Always switch off the tool before installing or

removing of the battery cartridge.

•

Hold the tool and the battery cartridge firmly

when installing or removing battery car-

tridge.

 Failure to hold the tool and the battery

cartridge firmly may cause them to slip off your

hands and result in damage to the tool and

battery cartridge and a personal injury.

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.

To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

•

Always install the battery cartridge fully until the

red indicator cannot be seen. If not, it may acci-

dentally fall out of the tool, causing injury to you

or someone around you.

•

Do not install the battery cartridge forcibly. If the

cartridge does not slide in easily, it is not being

inserted correctly.

NOTE:

•

The tool does not work with only one battery

cartridge.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys-

tem. This system automatically cuts off power to the

motor to extend tool and battery life.

The tool will automatically stop during operation if the

tool or battery are placed under one of the following

conditions. In some conditions, the indicators light up.

Overload protection

When the tool is operated in a manner that causes it to

draw an abnormally high current, the tool automatically

stops without any indication. In this situation, turn the

tool off and stop the application that caused the tool to

become overloaded. Then turn the tool on to restart.

Overheat protection for battery / tool

When the battery / tool is overheated, the tool stops

automatically without any indication. The tool does not

start even if pulling the switch trigger. In this situation,

let the battery / tool cool before turning the tool on

again.

NOTE:

 The battery overheat protection works only

with a battery cartridge with a star marking.

►

Fig.3:

1.

 Star marking

Overdischarge protection

►

Fig.4:

1.

 Battery indicator

When the remaining battery capacity gets low, the

battery indicator blinks on the applicable battery side.

By further use, the tool stops and the battery indicator

lights up about 10 seconds. In this situation, charge the

battery cartridge.

Indicating the remaining battery

capacity

Only for battery cartridges with the indicator

►

Fig.5:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Switch action

CAUTION:

•

Before installing the battery cartridge into the

tool, always check to see that the switch trigger

actuates properly and returns to the "OFF"

position when released.

►

Fig.6:

1.

 Lock-off button

2.

 Switch trigger

To prevent the switch trigger from being accidentally

pulled, a lock-off button is provided.

To start the tool, depress the lock-off button and pull the

switch trigger. Release the switch trigger to stop.
