8
upward to let it fully dry. (Fig.16)
4) Apply a few drops of the oil to the
points indicated by the arrows. (Fig.19)
5) Remount the blade on the clipper
body.
WARNING: Detach the clipper
f r o m t h e A C a d a p t o r b e f o r e
cleaning it in water.
B
If cleaning with brush
1) Use the cleaning brush to brush
off the cut hairs from the clipper
body and from around the blade.
(Fig.17)
2) Remove the blade and brush off
the cut hairs from the blade edge.
3) Brush the cut hairs out from between
t h e f i x e d b l a d e a n d t h e m o v i n g
blade. Press down on the lever for
cleaning in order to raise the moving
blade, and brush the cut hairs out
from between the blades. (Fig.18)
4) Apply a few drops of the oil to the
points indicated by the arrows. (Fig.19)
5) Remount the blade on the clipper
body.
Important notice
regarding environmental
protection
The built-in rechargeable Nickel-
M e t a l H y d r i d e b a t t e r y c o n t a i n s
s u b s t a n c e s w h i c h m a y b e
e n v i r o n m e n t a l l y h a r m f u l . B e f o r e
discarding your eletric hair clipper
please remove the battery and be
s u r e t h a t i t i s d i s p o s e d o f i n a n
environmentally friendly way.
<How to remove the built-in
rechargeable battery>
D i s c o n n e c t t h e c l i p p e r f r o m t h e
outlet when removing the battery.
Fully discharge the battery.
1) Remove the blade
A
and then
remove the three screws. (Fig.20)
2) Remove the bodycorner (housing).
(Fig.21)
3) Remove the four screws. (Fig.22)
4) R e m o v e t h e b l a d e a t t a c h m e n t
mounting
Q
and the lower cover
R
,
a n d t h e n p u l l o u t t h e m o t o r
S
.
(Fig.23)
5) Remove the plug mounting
T
, and
then take out the nickel metal hydride
battery. (Fig.24)
Be careful not to short the + and -
t e r m i n a l s o f t h e b a t t e r y a f t e r
removing it.
Specifications
Power source : 230V AC, 50Hz
Motor voltage : 1.2V DC
Charging time : 12hours
(
)
(
)
