Instructions for the User

6. DESCRIPTION OF FRONT PANEL CONTROLS

All the appliance's control and monitoring devices are placed together on
the front panel. The table below provides the key to the symbols used.

THERMOSTAT-TIMER KNOB

PT1

This knob allows you to set the time, select the
cooking temperature and duration and program
the cooking start and end times.

From now on,

for convenience it will be referred to as PT1.

For instructions on how to use it correctly, see
point  “7.3 First use” and “7.5 Programmed
cooking procedures”.

CURRENT TIME/PROGRAMMED COOKING OPERATION DISPLAY

DSP1

This display shows the current time or the cooking duration.

From now on, for convenience it will be referred to as DSP1.

TEMPERATURE DISPLAY

DSP2

This display shows the temperature set for the function required, or the
temperature set by the user.
Also visible are the function cutout light

 (see point “7.6.1 Child safety

lock-out function”) and the preheating level

 (see point “7.4 Selecting the

function”).

From now on, for convenience it will be referred to as DSP2.

FUNCTION DISPLAY

DSP3

This display shows (illuminated) all the cooking functions available for
selection. For instructions on how to select a cooking function, see point
“7.2 Operating modes”.

From now on, for convenience it will be referred to as DSP3.

34
