Instructions for the Installer

12.2 Positioning the oven

The appliance is designed for building-in to cabinets made from any heat-
resistant material. Comply with the dimensions shown in figures

1

,

2

,

and

3

. When installing under worktops, comply with the dimensions shown in

figure

1

-

3

. When installing under worktops incorporating combined hobs,

a gap of at least 110 mm must be left from any side wall, as shown in
figure

1

.

When installing in tall units, comply with the dimensions shown in figure

1

-

2

, bearing in mind that the top/rear of the unit must have an opening 80-

90 mm deep. Screw the 2 screws

A

into the inside of the frame (fig.

1

). For

installation under counter-top hobs, make sure that the rear/bottom of the
unit has an opening similar to that shown in figure

1

(ref.

B

). See the

instructions supplied with the hob for the relative positioning and fixing
procedures.

52
