ENGLISH

en

10

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

rating label, match with your power supply.

Australia: Always use a residual current device

(RCD) protected supply with a rated residual

current of 30 mA or less.

To ensure that the drill chuck is securely fitted:

After initial drilling (clockwise), use a

screwdriver to firmly tighten the safety screw inside

the drill chuck (if applicable / model-specific).

Caution left-handed thread !

(see Section 7.9.)

6.1 Assembly of additional handle (2)

For safety reasons, always use the additional

handle supplied.

Open the clamping ring by turning the additional

handle (2) counter-clockwise. Push the additional

handle onto the collar of the machine. Slide the

additional handle far enough forward so that it can

be turned. At the desired angle, pull it back and

tighten firmly.

7.1 Adjusting the Depth Stop

Loosen the additional handle (2). Set depth stop (5)

to the desired drilling depth and retighten additional

handle.

7.2 Setting direction of rotation,

transport lock (switch-on lock)

Do not activate the rotation selector switch (8)

unless the motor has completely stopped.

See page 2.

R

= Clockwise setting

L

= Counter-clockwise setting

0

= Central position: transport lock setting

(switch-on lock)

The drill chuck must be firmly screwed onto

the spindle and the safety screw inside the drill

chuck (if applicable / model-specific) must be firmly

tightened with a screwdriver. (Caution, left-handed

thread !) If rotated counterclockwise (e.g. when

screwing) it could otherwise become loose.

7.3 Selecting a gear

Select the desired gear by turning the

thumbwheel (1).
Change speed only when the machine

is in the process of running down

(briefly switch it on and off).

1st gear (low speed, high torque)

e.g. for screwdriving, drilling
2nd gear (high speed) e.g. for drilling

7.4

Switching Between Normal Drilling/

Impact Drilling

Select the desired operating mode by pushing the

sliding switch (6).

Drilling

Impact drilling


Work with high speed settings when impact drilling.

Impact drilling and normal drilling

only in a clockwise direction.

7.5 Preselect speed

Use the setting wheel (5) to preselect the maximum

speed. See page 4 for recommended drilling

speeds.

7.6 Switching on/off, changing speed

Switching on, speed:

 press the trigger (10).

SBE 760: The speed can be changed by

pressing in the trigger.
Release the trigger to switch off.

Continuous activation:

 While pressing on the

trigger (10), press in the locking button (9) and

then release the trigger. To switch off, press and

release the trigger (10) again.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore, always hold the machine with

both hands using the handles provided, stand in

a safe position and concentrate.

7.7 Tool change with (4)

chuck

See illustrations A on page 2.

Opening the drill chuck:

Grip the retaining ring and, using the other hand,

rotate the sleeve in the direction of the arrow -1-.
The grating sound (depending on function) which

may be heard after opening the drill chuck is

stopped by turning the sleeve in the opposite

direction.
If the chuck is very tightly secured, disconnect from

mains. Hold the chuck using an open-end spanner

at the flats on its head, and turn the sleeve

vigourously in the direction of the arrow -1-.

Clamping the tool

- Insert the tool -2- as far as it will go.

- Grip the retaining ring and, using the other hand,

rotate the sleeve in the direction of the arrow -3-

until the mechanical resistance which can be felt is

overcome.

-

Caution! The tool is not yet fully clamped!

Keep turning the sleeve (

it must "click" when

turning

) until it cannot be turned any further -

only

now

 is the tool

securely

 clamped.

In the case of a soft tool shank, retightening may be

required after a short period of drilling.

7.8 Tool change with a geared chuck (3)

See illustrations B on page 2.

Opening the chuck:

 Opening a geared chuck with

the chuck key -1-.

6. Initial Operation

7. Use
