PC-HWS1168_IM

12.10.18

38

Drip Tray for the Cups

1.

Slide the drip tray into the recess of the housing until it

stops. It must audibly click into place.

2.

Put on the stainless steel overlay.

3.

To remove the drip pan, lift it slightly.

Water

The fresh drinking water you fill in the water tank should

have a temperature of 22 °C to 28 °C. Do not fill with water

that has a temperature of above 35 °C or below 15 °C. This

could lead to deviations in the temperature of the dispensed

water.

Temperature Controller

Use this controller to select the temperature at which the

water is to be dispensed.

Push-Button  Switch  ON / OFF

Use this control to turn the appliance on and off. The

push-button switch performs the following functions when

engaged or disengaged:

Push-button

switch

OFF

disengaged:

ON

engaged:

The appliance

is switched off.

The appliance is

switched on.

Illuminated in red

---

Preheating phase

Illuminated in green

---

Water dispenser

Electric Connection

Ensure that your mains power corresponds with the speci

-

fications of the appliance. The specifications are printed on

the type label.

Connected Wattage

The total power consumption of this appliance can be up

to 2600 W. With this connected load a separate supply line

protected by a 16 A household circuit breaker is recom

-

mended.

 CAUTION: Overload!

•

If you use extension leads, these should have a cable

cross-section of at least 1.5 mm².

•

Do not use any multiple sockets, as this appliance is

too powerful.

Connection

1.  Check the switch position!

The push-button switch

must be disengaged.

2.

Connect the mains cable to a properly installed and

earthed wall outlet.

First Use

Prior to the first use, let the maximum tank content run

through the appliance while having the temperature setting

on 100 °C. This removes dust, which may have collected

during transport. Follow the instructions given under

 “Operation”. Do

not

 use this water for consumption.

Operation

 WARNING:

Danger of scalding due to escaping steam!

While preparing hot water keep your hands away from

the faucet.

1.  Open the lid of the water tank.

2.

You have two options to fill water into the water tank:

In case the water tank is placed on the housing, fill the

water by using a cup. You may also remove the water

tank beforehand and place it back filled.

3.  Fill the water tank with clean drinking water maximum up

to the “2.2 L” mark.

4.  Close the lid of the water tank.

5.

Place an empty container onto the drip tray.

6.  Use the temperature controller to select the desired

water temperature.

7.

Start the water dispenser by engaging the push-button

switch.

8.  Once the desired amount of water has been dispensed,

stop the water dispenser by disengaging the push-button

switch.

  CAUTION:

The water dispenser will not stop automatically!

De-scaling

The intervals at which you should remove lime-scale de

-

pend on hardness of the tap water and operating time. If the

preparation time increases significantly, de-calcification will

be necessary. Regardless, we recommend de-scaling the

appliance once a month.
•

Use only commercially available citrus acid-based de-

scaler.

•

Dose as indicated on packaging or instruction leaflet.

•  Dispense hot water with a temperature of 100 °C once.

Do not pour that water away immediately. As long as it

is hot you may still use it to de-scale the water faucet if

needed. Please observe the instructions that we have

included in the chapter “Cleaning”.

 WARNING:

•

Afterwards, let the maximum tank content run through

the appliance while having the temperature setting at

100 °C to rinse out residues of the de-scaling agent.

•  Do

not

 use this water for consumption.
