Use

The hood is conceived for the suction of cooking fumes and steam and is destined only
for domestic use.
The hood is designed to be used either for exhausting or filter version.

 Extraction version

In this case the fumes are conveyed outside of the building by means of a special pipe
connected with the connection ring located on top of the hood.


 CAUTION

!

The exhausting pipe is not supplied and must be purchased apart.
Diameter of the exhausting pipe must be equal to that of the connection ring.


 CAUTION

!

If the hood is supplied with active charcoal filter, then it must be removed.

Connect the hood and discharge holes on the walls with a diameter equivalent to the air
outlet (connection flange).
Using the tubes and discharge holes on walls with smaller dimensions will cause a
diminution of the suction performance and a drastic increase in noise.

Any responsibility in the matter is therefore declined.

!

Use a duct of the minimum indispensable length.

!

Use a duct with as few elbows as possible (maximum elbow angle: 90°).

!

Avoid drastic changes in the duct cross-section.

 Filtration version

The aspirated air will be degreased and deodorised before being fed back into the
room.
In order to use the hood in this version, you have to install a system of additional
filtering based on activated charcoal.


Installation

The minimum distance between the supporting surface for the cooking equipment on
the hob and the lowest part of the range hood must be not less than 50cm from electric
cookers and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a greater distance, this must be
adhered to.

  Electrical connection

The mains power supply must correspond to the rating indicated on the plate situated
inside the hood. If provided with a plug connect the hood to a socket in compliance with
current regulations and positioned in an accessible area, after installation. If it not fitted
with a plug (direct mains connection) or if the plug is not located in an accessible area,
after installation,  apply a double pole switch in accordance with standards which
assures the complete disconnection of the mains under conditions relating to over-
current category III, in accordance with installation instructions.


WARNING!

Before re-connecting the hood circuit to the mains supply and checking the efficient
function, always check that the mains cable is correctly assembled.
The hood is provided with a special power cable ; if the cable is damaged, request a
new one from Technical Service.

Mounting

Before beginning installation:

•

Check that the product purchased is of a suitable size for the chosen installation
area.

•

Remove the charcoal (*) filter/s if supplied (see also relative paragraph). This/these
is/are to be mounted only if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other supplied material inside the

hood (e.g. packets with screws (*), guarantees (*), etc.), eventually removing them
and keeping them.


This hood is designed for fitting in a cabinet or on some other support.

Maintenance

Cleaning

Clean using

ONLY

 a cloth dampened with neutral liquid detergent.

DO NOT CLEAN

WITH TOOLS OR INSTRUMENTS

. Do not use abrasive products.

DO NOT USE

ALCOHOL!

Always wear work gloves for all maintenance operations.

Grease filter

Fig. 8-13
Traps cooking grease particles.

The grease filter

 must be cleaned once a month using non aggressive detergents,

either by hand or in the dishwasher, which must be set to a low temperature and a short
cycle.  When washed in a dishwasher, the grease filter may discolor slightly, but this
does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.

Charcoal filter (Optional)

Fig. 12
It absorbs unpleasant odors caused by cooking.

The saturation of the

charcoal filter

 occurs after more or less prolonged use,

depending on the type of cooking and the regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least every four months.
The charcoal filter may NOT be washed or regenerated.
Remove the grease filters.
Apply one charcoal filter each side and hook in onto the hood.
Refit the grease filter.


Buying charcoal filters

The Charcoal filter can be bought at Samsung Service Website and Service Center.
Please refer to the last page of manual.

Replacing lamps

Disconnect the appliance from the electricity.

Warning!

Prior to touching the light bulbs ensure they are cooled down.

Extract the drawer completely.

Remove the suction gril to access the lamp area.
Remove the damaged light and replace it with a new one (see the table below):


Lamp

Power (W)

Socket

3 E14

Voltage (V)

Dimension (mm)

220-240

35x102 (Diameter

x Length)

ILCOS D Code

(according IEC 61231)

DRBB/C-3-220-240-E14-35/102


Put the grill back.
If the lights do not work, make sure that the lamps are fitted properly into their housings
before you call for technical assistance.
