23

INSTALLING THE HOOD

1) Drill a Ø8mm hole in the wall using the

installation template provided in the box with
the mounting hardware, (A,B,C,D) and insert
plastic plugs into these Ø8mm holes.

2) Considering the height of the place of

installation, drill Ø6mm holes in the wall using
a hammer drill (E,F) for the inner chimney slat
and insert plastic plugs Ø6mm into these holes.

WARNING

B

Make sure the plug is easily accessible so that it can be disconnected in case of

risk.

B

During installation, the power cable must not be compressed or crushed. If the

power cable is damaged, it must be replaced by an authorized service center or a qualified
electrician. This applies to any possible damage to the power cable in the future.

B

This product is not suitable for children over 8 years of age and persons with limited

physical, sensory or psychological skills only if they are supervised or instructed in the safe
use of the product and are aware of the risks associated with the product. Children must not
play with the product. Children under the age of 8 and without supervision should not clean or
maintain the product. Keep the product and cable out of the reach of children under 8 years
of age.

B

When connecting the hood to the duct, use a pipe with a diameter of 120 mm. For

maximum extraction performance, the pipe connection should be as short as possible, smooth
and with minimal bends.

B

The exhaust pipe is not supplied with the product, needs to be purchased. The

diameter of the exhaust pipe must be equal to the diameter of the connecting ring.
