GENERAL

Carefully read the following important information regarding
installation safety and maintenance. Keep this information
booklet accessible for further consultations. The appliance
has been designed for use in the ducting version (air exhaust
to the outside – Fig.1B), fi ltering version (air circulation on the
inside – Fig.1A) or with external motor (Fig.1C).

SAFETY PRECAUTION

1. Take care when the cooker hood is operating simultaneously
with an open fi replace or burner that depend on the air in the
environment and are supplied by other than electrical energy,
as the cooker hood removes the air from the environment
which a burner or fi replace need for combustion. The negative
pressure in the environment must not exceed 4Pa (4x10-5 bar).
Provide adequate ventilation in the environment for a safe
operation of the cooker hood. Follow the local laws applicable
for external air evacuation.

Before connecting the model to the electricity network:

- Control the data plate (positioned inside the appliance)
to ascertain that the voltage and power correspond to the
network and the socket is suitable. If in doubt ask a qualifi ed
electrician.
- If the power supply cable is damaged, it must be replaced
with another cable or a special assembly, which may be
obtained direct from the manufacturer or from the Technical
Assistance Centre.
- This device must be connected to the supply network
through eiter a plug

fused 3A

or hardwired to a

2 fase

spur

protected by

3A fuse.

2. Warning !
In certain circumstances electrical appliances may be a
danger hazard.
A) Do not check the status of the fi lters while the cooker
hood is operating
B) Do not touch bulbs or adjacent areas, during or straight
after prolonged use of the lighting installation.
C) Flambè cooking is prohibited underneath the cooker
hood
D) Avoid free fl ame, as it is damaging for the fi lters and
a fi re hazard
E )   Co n s t a n t l y   c h e c k   fo o d   f r y i n g   t o   avo i d   t h a t   t h e
overheated oil may become a fi re hazard
F )   D i s c o n n e c t   t h e   e l e c t r i c a l   p l u g   p r i o r   t o   a n y
maintenance.
G) This appliance is not intended for use by young children
or infi rm persons without supervision
H) Young children should be supervised to ensure they do
not play with the appliance
I) There shall be adequate ventilation of the room when
the rangehood is used at the same time as appliances
burning gas or other fuels
L) There is a risk of fi re if cleaning is not carried out in
accordance with the instructions

This appliance conforms to the European Directive EC/2002/96,
Waste Electrical and Electronic Equipment ( WEEE). By making
sure that this appliance is disposed of in a suitable manner,
the user is helping to prevent potential damage to the
environment or to public health.

The

 symbol on the product or on the accompanying

paperwork indicates that the appliance should not be treated
as domestic waste, but should be delivered to a suitable
electric and electronic appliance recycling collection point.
Follow local guidelines when disposing of waste. For more
information on the treatment, re-use and recycling of this
product, please contact your local authority, domestic waste
collection ser vice or the shop where the appliance was
purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried out by
specialised personnel.

• Electric Connection

The appliance has been manufactured as a class II, therefore
no earth cable is necessary.
The connection to the mains is carried out as follows:
BROWN =

 L

 line

BLUE =

 N

 neutral

I f not provided, connec t a plug for the elec trical load
indicated on the description label. Where a plug is provided,
the cooker hood must be installed in order that the plug is
easily accessible.
An omnipolar switch with a minimum opening of 3mm
between contacts, in line with the electrical load and local
standards, must be placed between the appliance and the
network in the case of direct connection to the electrical
network.

•

 The minimum distance between the support surfaces of

the cooking pots on the cooker top and the lowest part of
the cooker hood must be at least 65 cm. If a connection
tube composed of two parts is used, the upper part must
be placed outside the lower part. Do not connect the cooker
hood exhaust to the same conductor used to circulate hot air
or for evacuating fumes from other appliances generated by
other than an electrical source.
Before proceeding with the assembly operations, remove the
anti-grease fi lter(s) (Fig.6) so that the unit is easier to handle.
- In the case of assembly of the appliance in the suction version
prepare the hole for evacuation of the air.

•  We recommend the use of an air exhaust tube which has
the same diameter as the air exhaust outlet hole. If a pipe
with a smaller diameter is used, the effi

    ciency of the product

may be reduced and its operation may become noisier.

•

If your appliance has been designed for use in habitations

supplied with acentralised suc tion device per form the
following operations:
-The switch controls opening and closure of a valve using
a thermoelectical device. By placing the switch in the

ON

position, after a minute, the valve opens rotating 90° allow-
ing suction of the stale air. By placing the switch in the

 OFF

position, the valve closes after 100 seconds.

• Fixing to the wall

Drill the holes

A

 respecting the distances indicated (Fig.2). Fix

the appliance to the wall and align it in horizontal position
to the wall units. When the appliance has been adjusted,
defi nitely fi x the hood using the screws

A

 (Fig.4). For the vari-

ous installations use screws and screw anchors suited to the

ENGLISH

GB

- 4 -
