One active charcoal filter is needed for this and can be obtained from your usual retailer.
The filter removes the grease and smells from the extracted air before sending it back into the room through the upper outlet
grid.

INSTALLATION

ELECTRICAL CONNECTION

MOUNTING

Very heavy product; hood handling and installation must be carried out by at least two persons.

Before beginning installation:

•

•

•

•

•

•

Use a duct of the minimum indispensible length.

Use a duct with as few elbows as possible (maximum elbow angle: 90°).
Avoid drastic changes in the duct cross-section.
Use a duct as smooth as possible inside.
The duct must be made of certified material.

!
!
!
!
!

FILTER VERSION

The  minimum  distance  between  the  supporting  surface  for  the  cooking  equipment  on  the  hob  and  the  lowest  part  of  the
range hood must be not less than 50cm from electric cookers and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a greater distance, this must be adhered to.

The mains power supply must correspond to the rating indicated on the plate situated inside the hood. If provided with a plug
connect the hood to a socket in compliance with current regulations and positioned in an accessible area, after installation. If
it not fitted with a plug (direct mains connection) or if the plug is not located in an accessible area, after installation, apply a
double  pole  switch  in  accordance  with  standards  which  assures  the  complete  disconnection  of  the  mains  under  conditions
relating to over-current category III, in accordance with installation instructions.

Warning!

 Before re-connecting the hood circuit to the mains supply and checking the efficient function, always check that the

mains cable is correctly assembled.
The hood is provided with a special power cable ; if the cable is damaged, request a new one from Technical Service.

Check that the product purchased is of a suitable size for the chosen installation area.
Remove  the  charcoal  (*)  filter/s  if  supplied  (see  also  relative  paragraph).  This/these  is/are  to  be  mounted  only  if  you
want to use the hood in the filtering version.
Check  (for  transport  reasons)  that  there  is  no  other  supplied  material  inside  the  hood  (e.g.  packets  with  screws  (*),
guarantees (*), etc.), eventually removing them and keeping them.
If  possible,  disconnect  and  move  freestanding  or  slide-in  range  from  cabinet  opening  to  provide  easier  access  to  rear
wall/ceiling.  Otherwise  put  a  thick,  protective  covering  over  countertop,  cooktop  or  range  to  protect  from  damage  and
debris. Select a flat surface for assembling the unit. Cover that surface with a protective covering and place all canopy
hood parts and hardware in it.
In addition check whether near the installation area of the hood (in the area accessible also with the hood mounted) an
electric socket is available and it is possible to connect a fumes discharge device to the outside (only suction version).
Carry  out  all  the  masonry  work  necessary  (e.g.  installation  of  an  electric  socket  and/or  a  hole  for  the  passage  of  the
discharge tube).

Expansion  wall  plugs  are  provided  to  secure  the  hood  to  most  types  of  walls/ceilings.  However,  a  qualified  technician  must
verify  suitability  of  the  materials  in  accordance  with  the  type  of  wall/ceiling.  The  wall/ceiling  must  be  strong  enough  to  take
the weight of the hood. Do not tile, grout or silicone this appliance to the wall. Surface mounting only.
