cloth

 and

 not too concentrated liquid

detergent. Do not use abrasive substances.

Attention! Hold the panel with both hands
when dismantling and re-mounting in
position to avoid it falling and causing
damage to people or things.
Dismantling:

-pull the panel (FRONT SIDE) downward with
decision,
-push to the left the small lever located on the

right side of the panel,

-unhook it from the back hinges.

Cleaning:

Clean the suction panel with the same
frequency as the fats filter using a cloth
soaked in neutral liquid detergents.


Avoid the use of products containing

abrasives. DO NOT USE ALCOHOLS.

Montage:

The panel must be hooked at the back and
fixed in front fitted into the pins for the
purpose on the surface of the hood.

Attention!

always check that the panel is well

fixed in its place.

Grease filter

Fig. 13-25
Traps cooking grease particles.

This must be cleaned at least once a month
(or when the filter saturation indication system
- envisaged on the model in possession -
indicates this necessity), using non-
aggressive detergents, in a dishwasher, which
must be set to a low temperature and a short
cycle (Tmax: 70°C).
When washed in a dishwasher, metal parts
may discolour slightly.
The filter must be dried in an oven for one
hour at a max temperature of 100°C; if the
filter is still moist, repeat the operation.
Replace the filter at least every 2 years.
To remove the grease filter, pull the spring
release handle.

Charcoal filter (filter version only)

Fig. 24
It absorbs unpleasant odours caused by
cooking.

The saturation of the charcoal filter occurs
after more or less prolonged use, depending
on the type of cooking and the regularity of
cleaning of the grease filter.
In any case it is necessary to replace the
cartridge at least every four mounths (or when
the filter saturation indication system – if
envisaged on the model in possession –
indicates this necessity).The charcoal filter
may NOT be washed or regenerated.

Circular carbon filter

Apply one on each side as cover to both the
shield grids of the motor impeller, then turn
clockwise.
For the disassembly, turn counter-clockwise.

Replacing lamps

The hood is equipped with a lighting system
based on LED technology.
The LEDs guarantee an optimum lighting, a
duration up to 10 times as long as the
traditional lamps and allow to save 90%
electrical energy.

For replacement, contact the technical
service.

46
