ELECTRICAL CONNECTIONS

D

(Section reserved for qualified installers)

WARNING! Before doing any work inside the range hood, disconnect the appliance from the mains power supply.
Check that the wires inside the range hood are not disconnected or cut; if this is the case, contact your nearest service centre. The
electrical connections must be performed by qualified personnel.

The connections must be performed in compliance with the legal standards in force. Check that the relief valve and the electrical system
are able to support the load of the appliance (see the technical specifications in point B).
Some types of appliance are supplied with a cable without plug; in this case, “standardised” plugs must be used, keeping in mind that:
- the yellow-green wire must be used for the earth,
- the blue wire must be used for the neutral,
- the brown wire must be used for the phase; the cable must not come into contact with hot parts (over 70°C).
- fit a plug that is suitable for the load to the power cable, and connect it to a suitable power outlet.
For appliances that come supplied with cable and plug please ensure they are plugged into a circuit suitable for this appliance.
Please refer to a qualifed person. (See technical specifications in point B).

The manufacturer declines all liability if the safety standards are not observed.

E

RANGE HOOD WITH OUTSIDE DISCHARGE (exhaust)

In this version, the fumes and steam from the kitchen are conveyed outside through an exhaust duct.
The exhaust conveyor that protrudes from the upper part of the range hood must be connected to a duct that carries the fumes and steam
outside. In this version, the charcoal filters, if fitted, should be removed; to do this, see the instructions in point F. There must be adequate
ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels, according to the standard.

Deviation for Germany:
When the range hood and appliances supplied with energy other than electricity are simultaneously in operation, the negative pressure
in the room must not exceed 4 Pa (4x10 E-5 bar).

F

RECIRCULATING RANGE HOOD (with filter)

In this version, the air passes through charcoal filters for purification, and is then recirculated back into the kitchen.
Check that the charcoal filters are fitted to the motor, and if not, install them as described in the instructions in point H.
If the hood is of filtering type, remove the non-return valve fitted at the motor’s outlet.

  For maximum efficiency, the third speed should be used when there are strong odours or a lot of steam, the second speed in normal

conditions, and the first speed for keeping the air clean with minimum energy consumption. The range hood should be switched on
when starting to cook, and left on until the odours disappear.

G

OPERATION

ELECTRONIC CONTROL PANEL

Light pushbutton

 • ON: light on (the pushbutton is lit);
 • OFF: light off;

Pushbutton -

 Press to reduce motor speed
 Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the timer LEDs).

Pushbutton +

 Press to increase motor speed
 Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the timer LEDs).
 (In the 4-speed version the pushbutton + blinks. The fourth speed remains on for a set duration of time. After 7 minutes the motor returns
to the third speed).

Mode pushbutton

 Function: it turns hood motor on and off.
 The function

“desired speed”

 enables to start the motor at the speed that was selected before the hood was last turned off.

 Optional: version with remote control (some versions only).

WARNING:

Install the hood away from sources of electromagnetic waves, as these could affect the correct operation of the electronic system.
Maximum operating distance: 5 metres. The maximum operating distance could be less than 5 metres in case of electromagnetic inter-
ference by other equipment.
 Light pushbutton on remote control:  light on/off.
 – and + pushbutton: increase/decrease speed (to start the motor press either the + or the – pushbutton).
 Timer pushbutton: see instructions below.

Timer and ‘filter clogged’ alarm pushbutton

 • This function allows the automatic turning off of the hood after running for 15 minutes at the speed previously set (the pushbutton
shows a flickering light).
 • After about 30 hours of running the pushbutton indicates the need for washing the metal filters (the pushbutton shows a solid red light).
To disable the alarm press the pushbutton for a few seconds until the red light turns off. Then turn the hood off and on again to check
that the alarm has disappeared.
