22

Phase 2

-  Hook the hood on the support bar.
- Adjust the alignment of the hood, using the fixing screws (Fig. 2): these can be reached by

opening panel (D) and removing anti-grease metal filters (E). The upper screw (B) adjusts the
distance from the wall, the lower one (C) the vertical scrolling.

- To prevent the hood from falling due to a pressure below, fasten it to the wall with two ex-

pansion bolts and relative screw via the appropriate holes (F) inside the hood.

Phase 3 (exhaust version only)

- To install the exhaust version hood, connect to the PVC tube (N) protruding from the hole

on the cover (G) of the hood.  In case of discharge air from the rear, connect fitting (M) to a
suitable elbow shaped of flexible tube (Fig. 3); subsequently, place the cover in its original
position.

MIRA WALL HOOD ASSEMBLY (fixed or telescopic chimney)

Phase 1

- Place on the wall the support bar (A) (Fig. 1), at the same height of the cooker resulting from

the sum of the heights X+Y+320 mm (fig. 4).

- With a spirit level, verify the horizontal alignment and mark  two drilling points at the edges

of bar n. 2.

- Drill, insert n. 2 expansion bolts of 8 mm and fasten the bar with the relative screws.

Phase 2

- Hook the hood on the support bar (Fig. 5).
- Adjust the alignment of the hood, using the fixing screws.
-  The upper screw (B) adjusts the distance from the wall, the lower one (C) the vertical scrol-

ling.

Phase 3

-  To prevent the hood from falling due to a pressure below, fasten it to the wall with an expan-

sion bolt and relative screw, using the appropriate holes on the hood rear.

- In case of exhaust version, connect the output fittings of the fan to the external discharge,

using a suitable tube (see fig. 6).

-  Carry out electric connection only after having disconnected the electric power supply of the

hood.

Phase 4

Mira with fixed chimney:

 join the chimney (G) to the hood body and fasten it using screws (V1).

Mira with chimney+telescopic extension:

 Place extension (H) in the chimney (G) and fasten

them to the body of the hood using the 8 screws (V1).

In case the hood is assembled with a kitchen shelf, use screws (V1) with suitable length. The
shelf must be properly fastened autonomously, so that it does not weight down the hood.

- Scroll the extension (H) until reaching the desired height. Once the right position is found (L),

verify the horizontal alignment with a spirit level and mark n. 2 drilling points at the edges.

- Drill, insert n. 2 expansion bolts of 4mm ø and fasten the bracket (L) with the relative screws.
-  Tighten the extension (H) to the bracket (L) using screws (M).
-  Power the hood complying with the regulations in force (sec. D).

ASSEMBLY INSTRUCTIONS OF ALTAIR/MIRA ISLAND
Phase 1

- Due to packaging and transport requirements, the hood is provided with an extension and
