5-6) Insert the range hood power cable (CA) in the hole of the support cover plate (C) and

connect it to the terminal (MA) complying with the provisions of sect D.

(Fig. E)

1)  Place the terminal inside the support (SC);
2)  lift the support cover plate (C);
3)  tighten the support cover plate (C) to the support (SC) using 2 screws (V4).
4)  Power the range hood electrically.

L2   INSTRUCTIONS FOR HOOD INSTALLATION WITH WALL BRACKET

(Fig. A)

1)  Cut off the voltage from the electrical system that powers the hood. Make sure there is a

set-up for the electrical power supply (Solution A or B) for the hood on the wall it is being
installed on, according to regulations in force.

2)  Position the hood bracket (SP) at distance Y, considering that the distance between the

hood and cooking surface must be approximately 60-65 cm.

3)  Attach the hood bracket (SP) using 2 Ø 8 mm dowels and relative V1 screws. Warning, if the

power supply cable for the hood system (CAI) is positioned behind the hood bracket (SP)
(Solution A), pass it through the hole (F) on the bracket.

(Fig. B)

1A)

 Solution A ->

-  Momentarily place the hood near the hood bracket (SP) and connect the power supply

clamp (MA) to the power supply cable of the hood (CA), observing the phase, neutral and
earth requirements (see sec. D), cutting off any excess cable.

-  Place the clamp and the power supply cable between the back of the hood and the hood

bracket (SP) so that they are hidden.

1B)

 Solution B (more common) ->

the electrical outlet (PE) is placed near the hood. In this case it is necessary to install a
plug with a phase, neutral and earth on the hood power supply cable (CA), observing the
regulations in force.

(Fig. C)

1)  Insert the heads of the V4 screws assembled on the hood into the holes on the hood bra-

cket (SP).

2)  Move the hood so that the heads of the screws fit into the slots on the hood bracket.
3-4) Permanently fasten the bracket (SP) to the hood using the 4 V5 screws provided.

(only for Solution B)

Connect the hood to the electrical power mains.

-  Electrically power the hood.
