15

ENGLISH

 USING THE RADIO CONTROL

WARNINGS!:

Place the hood away from sources of electro-

magnetic waves (e.g. microwave ovens), which

could interfere with the radio control and with the hood

electronics. The maximum operating distance is 5 me-

tres, that may vary according to the presence of electro-

magnetic interferences.

Radio control operated at 433.92MHz.

The radio control consists of two parts:

- the receiver built into the hood;

- the transmitter shown here in the figure.

DESCRIPTION OF TRANSMITTING COMMANDS

Press

briefly

UP

Motor switch-on and speed increase from 1 to 4.
Speed 4 is only active for a few minutes.

Pressure

prolonged

Lifting the hood

Activated only with the fan not working.
Stop:
- when the upper microswitch is reached
- pressing the

 or

 or

.

Press

briefly

DOWN

Decremento velocità e spegnimento motore

Pressure

prolonged

Lowering the hood

Activated only with the fan not working.
Stop:
- when the lower microswitch is reached
- pressing the

 or

 or

.

Press

briefly

Accensione / spegnimento luce

Pressure

prolonged

Cambio tonalità della luce da 2700K a 5600K

Press

briefly

TIMER

: Autospegnimento del motore dopo 15min.

The function is deactivated if the

 or

 button

is pressed.

RADIO CONTROL CODE CHANGE

With only one radio control, go directly to point 2.
With several radio controls in the same room, a new code can be created by
following the procedure below.

Disconnect the power to the hood before starting the procedure.

1) - CREATE A NEW CODE

The procedure is to be carried out on the radio control.
•  Press LIGHT

 and TIMER

 simultaneously until the display starts flashing.

•  Press DOWN

 on the radio control: saving is confirmed by three brief flash-

es of the display. The new code cancels and replaces the previous default
code.

Reconnect the hood to the electrical power supply, making sure

that the lights and motor are off.

2A) - ASSOCIATING THE RADIO CONTROL WITH THE HOOD

           USING THE ELECTRONIC PUSHBUTTON PANEL

press TIMER (

)

on the hood pushbutton panel

 for 2 seconds:

the red LED lights up.
press any key on the radio control within 10 seconds. .

RESTORING DEFAULT CODE

the procedure is to be carried out if the hood is disposed of, sold or transferred.

Disconnect the power to the hood before starting the procedure.

•  Press UP

 and DOWN

 simultaneously on the radio control for more

than 5 seconds: reset is confirmed by three brief flashes of the display.

•  Reconnect the hood to the electrical power supply.
•  Proceed with associating the hood and the radio control, as described in point

2.

MAINTENANCE

Before cleaning or carrying out maintenance operations, discon-

nect the equipment by removing the plug or switching off the

main switch.

Do not use detergents containing abrasive, acidic or corrosive substances

or abrasive cloths.

Regular maintenance guarantees proper operation and performance over time.
Special attention is to be paid to the

metal anti-grease filters

: frequent clean-

ing of the filters and their supports ensures that no flammable grease is accu-
mulated.

CLEANING OF EXTERNAL SURFACES

You are advised to clean the external surfaces of the hood

at least once every

15 days

to prevent oily substances and grease from sticking to them. To clean

the brushed stainless steel hood, the Manufacturer recommends using "Magic
Steel" wipes.
Alternatively

and for all the other types of surfaces

, it can be cleaned using a

damp cloth, slightly moistened with mild, liquid detergent or denatured alcohol.
Complete cleaning by rinsing well and drying with soft cloths.

Do not use too much moisture or water around the push button

control panel and lighting devices in order to prevent humidity

from reaching electronic parts.

The glass panels can only be cleaned with specific, non-corrosive or non-abra-
sive detergents using a soft cloth.
The Manufacturer declines all responsibility for failure to comply with these in-
structions.

CLEANING OF INTERNAL SURFACES

Do not clean electrical parts, or parts related to the motor inside

the hood, with liquids or solvents.

For the internal metal parts, see the previous paragraph.

METAL ANTI-GREASE FILTERS

It is advised to

frequently

wash the metal filters (

at least once a month

) leaving

them to soak in boiling water and cleaning solution for 1 hour, taking care not
to bend them.
Do not use corrosive, acid or alkaline detergents.
Rinse them well and wait for them to be completely dry before reassembling
them.
Washing in a dishwasher is permitted, however, it may cause the filter material to
darken: to reduce the possibility of this problem from happening, use low-tem-
perature washes (55°C max.).
To extract and insert the metal anti-grease filters see the assembly instructions.
