13

INSTALLATION

C

(Section reserved for qualified installers of the range hood)

Minimum distance between the higher part of the cooker and the lower part
of the hood: usually, when a hood is fitted on a gas appliance, this distance
must be at least 65 cm.(25,6”) see Fig. 01.
However, on the basis of EN60335-2-31 of 11-07-2002 from TC61 (sub-clause
7.12.1 meeting 15 agenda item 10.11), in the case of a Diamante/Gleam hood
the distance can be reduced to 53 cm, but any instructions to the contrary for
the cooker must be taken into consideration.
In the extractor version the whole pipe must have a diameter similar or big-
ger than the one linked to the hood.  In the horizontal parts the pipe must be
inclined slightly (about 10%)  to the top in order to better channel the fumes
outside.
Avoid using angled pipes, make sure that the pipes are at least of the mini-
mum length.
Comply with the current regulations on air discharge into the atmosphere.
If a boiler, stove, fireplace, etc. that uses gas or other fuels is being used at
the same time, make sure the room where the fumes are extracted is well
ventilated, in compliance with the current regulations.
Mounting instruction: see section “O” of the booklet.

ELECTRICAL CONNECTIONS

D

(Section reserved for qualified installers)

WARNING!
Before doing any work inside the range hood, disconnect the appliance from
the mains power supply.
Check that the wires inside the range hood are not disconnected or cut; if this
is the case, contact your nearest service centre. The electrical connections
must be performed by qualified personnel.

The connections must be performed in compliance with the legal standards in
force. Check that the relief valve and the electrical system are able to support
the load of the appliance (see the technical specifications in point B).
Some types of appliance are supplied with a cable without plug; in this case,
“standardised” plugs must be used, keeping in mind that:
- the yellow-green wire must be used for the earth,
- the blue wire must be used for the neutral,
- the brown wire must be used for the phase; the cable must not come into

contact with hot parts (over 70 °C).

- fit a plug that is suitable for the load to the power cable, and connect it to a

suitable power outlet.

For appliances that come supplied with cable and plug please ensure they are
plugged into a circuit suitable for this appliance.
Please refer to a qualifed person. (See technical specifications in point B).

The manufacturer declines all liability if the safety standards are not ob-
served.
