3

Recommendations

and suggestions

•  The Instructions for Use apply to

several versions of this appliance.

Accordingly, you may find descriptions

of individual features that do not apply

to  your  specific  appliance.

•  The manufacturer will not be

held liable for any damages

resulting from incorrect or improper

installation.

•  The minimum safety distance

between the cooker top and the

extractor hood is 650 mm (some

models can be installed at a

lower height, please refer to the

paragraphs on working dimensions

and installation).

•  Check that the mains voltage

corresponds to that indicated on

the rating plate fixed to the inside

of the hood.

•  For Class I appliances, check

that the domestic power supply

guarantees adequate earthing.

Connect the extractor to the

exhaust  flue  through  a  pipe  of

minimum diameter 120 mm. The

route of the flue must be as short

as possible.

•  Do not connect the extractor

hood to exhaust ducts carrying

combustion fumes (boilers,

fireplaces,  etc.).

•  If the extractor is used in conjunction

with non-electrical appliances

(e.g. gas burning appliances),

a  sufficient  degree  of  aeration

must be guaranteed in the room

in  order  to  prevent  the  backflow

of exhaust gas. The kitchen must

have an opening communicating

directly with the open air in order

to guarantee the entry of clean air.

When the cooker hood is used

in conjunction with appliances

supplied with energy other than

electric, the negative pressure in

the room must not exceed 0,04

mbar to prevent fumes being

drawn back into the room by the

cooker hood.

•  In the event of damage to the

power cable, it must be replaced

by the manufacturer or by the

technical service department, in

order to prevent any risks.

•  If the instructions for installation

for the gas hob specify a greater

distance  specified  above,  this

has to be taken into account.

Regulations concerning the

discharge of air have to be fulfilled.

•  Use only screws and small parts

in support of the hood.

Warning:

 Failure to install

the  screws  or  fixing  device  in

accordance with these instructions

may result in electrical hazards.

•  Connect the hood to the mains

through a two-pole switch having

a contact gap of at least 3 mm.

•  This suction Hood can be used in

combination with a Gas hob with

the following characteristics:

•  Total maximum power 12.4kW.

•

5  burners  as  shown  in  the  figure.

3

•  Se le istruzioni di installazione  del piano  cottura a gas specificano  una

distanza maggiore di quella  sopra  indicata, è necessario  tenerne  conto.

Devono essere rispettate tutte le normative riguardanti lo scarico dell'aria.

•  Usare solo viti e minuteria di tipo idoneo per la cappa.

Avvertenza

: la mancata installazione delle viti o dei dispositivi di fissaggio

in conformità alle presenti istruzioni può comportare rischi di scosse

elettriche.

•  Collegare la cappa all'alimentazione di rete mediante un interruttore

bipolare con distanza tra i contatti di almeno 3 mm.

•  Questa cappa aspirante può essere utilizzata in combinazione con un

piano cottura a gas dotato delle seguenti caratteristiche:

• Potenza massima totale 12,4 kW

• 5 fuochi come illustrato nella figura

• Potenza massima totale 7,7 kW

• 4 fuochi come illustrato nella figura

• Potenza massima totale  4,7 kW

• 2 fuochi come illustrato nella figura

• Potenza massima totale 9,4 kW

• 4 fuochi come illustrato nella figura

2,8Kw

2,8Kw

1,9Kw

2,8Kw

1,9Kw

2,8Kw

1,9Kw

2,8Kw

1,9Kw

2,8Kw

1,9Kw

1,9Kw

1,1Kw

Oppure
