27

Operation

Use the high suction speed in cases of concentrated kitchen
vapours.  It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.

Note:

 if the hood does not work, make sure that it is ON by

using the ON/OFF button.
The button is inside the hood and can be reached by
removing the grease filter.

Fig. 19

Using the remote control

The remote control is able to control all the functions of the
hood:

Select the suction speed (power)

 Light

ON/OFF

 Not

implemented

 Not

implemented

Selecting the suction speed (power):

Press the "

◄

" key or the "

►

" key until you see the symbol

relating to the “Select the suction speed (power)” function.
Press the “+” key or the “-” key or the "

■

" key respectively to

increase or diminish or switch off (stand-by) the speed
(suction power).


Light ON/OFF:

Press the "

◄

" or "

►

" button, until the LED corresponding to

the "Light ON/OFF" symbol appears on the remote control.
Press the “+” or “-” button to put on or off the lights.
Press the "

■

" to change the status of the lights, from off (all

lights) to on (all lights) and vice-versa.

Configuration of the remote control

To enable the remote control, proceed as follows:
Press the "

◄

" or "

►

" button until you can see on the remote

control the symbol "

" related to the function “Reset and

configuration of the filter saturation signalling” and press
continuously on the central button "

■

" for at least 5 seconds.

An audible signal indicates the successful configuration.

Maintenance of the remote control

Cleaning the remote control:

Clean the remote control with a damp cloth and a neutral
solution of detergent without abrasive substances.


Changing the battery:

•

Open the battery casing using a small screwdriver with a
flat point.

•

Change the finished battery with a new one of 12 V type
MN21/23

In inserting the new battery respect the polarity indicated
on the battery casing!

•

Close the battery casing up again.

Disposal of the batteries

Ultimate disposal of the batteries should be handled according
to all national laws and regulations. Do not place used
batteries in your regular waste.
Ultimate disposal of the batteries must be done safely

.

Contact your local waste management officials for other
information regarding the environmentally sound collection,
recycling, and disposal of the batteries.

Maintenance

ATTENTION!

Before performing any maintenance operation,

isolate the hood from the electrical supply by switching off at
the connector and removing the connector fuse.
Or if the appliance has been connected through a plug and
socket, then the plug must be removed from the socket.

Cleaning

The cooker hood should be cleaned regularly (at least with the
same frequency with which you carry out maintenance of the
fat filters) internally and externally.  Clean using the cloth
dampened with neutral liquid detergent. Do not use abrasive
products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning

recommendations of the cooker hood and replacement of the
filters may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to
the motor or any fire damage linked to inappropriate
maintenance or failure to observe the above safety
recommendations.
The hood should be cleaned regularly (at least with the same
frequency with which you perform the maintenance of the
grease filters) internally and externally.
The chimney and the body of the hood are produced in

CRISTALPLANT

®

.

Note: For more details on the material

CRISTALPLANT

®

 and

the Manufacturer, visit

www.cristalplant.it

Maintenance of CRISTALPLANT

®

 DAILY

CARE

CRISTALPLANT

®

 requires an easy and quick daily care.

It is enough to clea

CRISTALPLANT

®

 using soap and

water or common detergents to remove most of the dirt
and stains that may be deposited on the surface. It is
particularly recommended to rinse the surface well and to
use gel or abrasive detergents with abrasive sponges like
“Scotch Brite©” as in attached sample; doing that way,
the original matt finish, distinguishing feature of

CRISTALPLANT

®

, will keep untouched.

HOW TO PREVENT FROM DAMAGES

The surface is generally strongly resistant against stains
and spots; nonetheless aggressive chemical products,
such as acetone, trichloroethylene, strong acids or bases
are not recommended. After long contact periods, several
substances like ink, cosmetics and dyes, may leave
