26

filter(s) when necessary to maintain a good grease filter
efficiency. Use the maximum diameter of the ducting system
indicated in this manual to optimize efficiency and minimize
noise.

Additional Installation Specifications:

Use only the fixing screws supplied with the product for
installation or, if not supplied, purchase the correct screws
type.
Use the correct length for the screws which are identified in
the Installation Guide.
In case of doubt, consult an authorised service assistance
centre or similar qualified person.

WARNING!

Failure to install the screws or fixing device in

accordance with these instructions may result in electrical
hazards.

Use

The hood is conceived for the suction of cooking fumes and
steam and is destined only for domestic use.
The hood is designed to be used either for exhausting or filter
version.

 Ducting version

In this case the fumes are conveyed outside of the building by
means of a special pipe connected with the connection ring
located on top of the hood.

Attention

! The exhausting pipe is not supplied and must be

purchased apart.
Diameter of the exhausting pipe must be equal to that of the
connection ring.
In the horizontal runs the exhausting pipe must be slightly
slanted (about 10°) and directed upwards to vent the air easily
from the room to the outside.
Attention! If the hood is supplied with active charcoal filter,
then it must be removed.

Connect the hood and discharge holes on the walls with a
diameter equivalent to the air outlet (connection flange).
Using the tubes and discharge holes on walls with smaller
dimensions will cause a diminution of the suction performance
and a drastic increase in noise.

Any responsibility in the matter is therefore declined.

!

Use a duct of the minimum indispensible length.

!

Use a duct with as few elbows as possible (maximum
elbow angle: 90°).

!

Avoid drastic changes in the duct cross-section.

!

Use a duct as smooth as possible inside.

!

The duct must be made of certified material.

 Filter version

One active charcoal filter is needed for this and can be
obtained from your usual retailer.
The filter removes the grease and smells from the extracted
air before sending it back into the room through the upper
outlet grid.


Installation

Specialised personnel must carry out both the electrical
and the mechanical installation.

The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the
range hood must be not less than 65cm from electric cookers
and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation,  apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in
accordance with installation instructions.

Warning!

 Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that
the mains cable is correctly assembled.
The hood is provided with a special power cable ; if the cable
is damaged, request a new one from Technical Service.

Mounting

The accessories for ceiling mounting are not provided as
ceilings of different materials require different types of fixing
accessories.
Use mounting systems suitable for the ceilings of the
premises and the weight of the equipment.
For more details and in case of doubt, in order to ensure
proper installation of the product, we recommend that you
contact a dealer and a specialized technician.
The chimney is a CRISTALPLANT ® product, it should be cut
to size (see also illustrative drawings).
The installation of the hood and the cut of the chimney must
be performed by a qualified technician using suitable cutting
systems.
For cutting, we recommend the use of the Widia tools, and
equipment (e.g., band saw or similar) capable of cutting
marble, wood and mineral materials.
If possible, we recommend that you perform a cut in the
excess part of the chimney to check the suitability of the tool.
Visit www.cristalplant.it for more details on the material and
manufacturer.

The warranty will not be effective in the case of cosmetic
defects or damages caused and/or arising from failure to
comply with the above provisions, as the assembly and the
cutting of the chimney are activities pertaining to and under
the full responsibility of a third party other than the
Manufacturer.
