19

Filter Saturation indicator lights

The hood signals at regular intervals that the filters must be

serviced.

 Keys

"

" and "

" lit and flashing very slowly:

service the grease filter.

   Keys  "

" and "

" lit and flashing quickly: service

the odour filter.

 Note:

The filter saturation warning signal is visible within

the first 10 seconds after the hood is switched on.

Reset filter saturation indicator:

Press and hold the keys "

" and "

"

The keys will flash quickly to confirm that reset has been

completed

Activation of filter saturation indicators

Note: this operation must be performed with the hood off.

- Grease filter

  Push and hold down the keys "

" and "

" to

activate the function

the keys light up flashing very slowly, indicating that the

grease filter indicator can be activated

 Note: Push the keys " " and " " to activate or deactivate

- Odour filter

  Push and hold down the keys "

" and "

" to

activate the function

  the keys light up flashing quickly, indicating that the

odour filter indicator can be activated (normally deactivated)
 Note: Push the keys " " and " " to activate or deactivate

Maintenance

Cleaning

Clean using ONLY a cloth dampened with neutral liquid

detergent.  DO NOT CLEAN WITH TOOLS OR

INSTRUMENTS. Do not use abrasive products. DO NOT USE

ALCOHOL!

Grease filter

Fig. 7-11

Traps cooking grease particles.

This must be cleaned once a month (or when the filter

saturation indication system – if envisaged on the model in

possession – indicates this necessity)  using non aggressive

detergents, either by hand or in the dishwasher, which must

be set to a low temperature and a short cycle.

When washed in a dishwasher, the grease filter may discolor

slightly, but this does not affect its filtering capacity.

To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only)

Fig. 14

It absorbs unpleasant odors caused by cooking.

The charcoal filter can be washed once every two months (or

when the filter saturation indication system – if envisaged on

the model in possession – indicates this necessity)   using hot

water and a suitable detergent, or in a dishwasher at 65°C (if

the dishwasher is used, select the full cycle function and leave

dishes out).

Eliminate excess water without damaging the filter, then put it

in the oven for 10 minutes at 100° C to dry completely.

Replace the mattress every 3 years and when the cloth is

damaged.

•  Montage

Open the steam screen and remove the grease filter.

Install the carbon filter on the back of the grease filter and

fix with two rods.

•  To dismantle the filter act in the reverse manner.

Replacing lamps

The hood is equipped with a lighting system based on LED

technology.

The LEDs guarantee an optimum lighting, a duration up to 10

times longer than the traditional lamps and allow to save 90%

electrical energy.

For replacement, contact the technical service.
