Use

The hood is designed to be used either for exhausting or filter

version.

 Extraction version

In this case the fumes are conveyed outside of the building by

means of a special pipe connected with the connection ring

located on top of the hood.

 CAUTION!

The exhausting pipe is not supplied and must be purchased

apart.

Diameter of the exhausting pipe must be equal to that of the

connection ring.

 CAUTION!

If the hood is supplied with active charcoal filter, then it must

be removed.

Connect the hood and discharge holes on the walls with a

diameter equivalent to the air outlet (connection flange).

Using the tubes and discharge holes on walls with smaller

dimensions will cause a diminution of the suction performance

and a drastic increase in noise.

Any responsibility in the matter is therefore declined.

!  Use a duct of the minimum indispensable length.

!  Use a duct with as few elbows as possible (maximum

elbow angle: 90°).

!  Avoid drastic changes in the duct cross-section.

 Filtration version

The aspirated air will be degreased and deodorised before

being fed back into the room.

In order to use the hood in this version, you have to install a

system of additional filtering based on activated charcoal.

Installation

Mounting

Before beginning installation:

•  Check that the product purchased is of a suitable size for

the chosen installation area.

•  Remove the charcoal (*) filter/s if supplied (see also

relative paragraph). This/these is/are to be mounted only

if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with

screws (*), guarantees (*), etc.), eventually removing

them and keeping them.

Expansion wall plugs are provided to secure the hood to most

types of walls/ceilings. However, a qualified technician must

verify suitability of the materials in accordance with the type of

wall/ceiling. The wall/ceiling must be strong enough to take

the weight of the hood.

Do not tile, grout or silicone this appliance to the wall.

Surface mounting only.

Elica Connect

The hood features a WiFi function for remote connection via

the Elica Connect app.

Minimum system requirements:

•  2.4GHz WiFi b/g/n wireless router

•  Android or iOs Smartphone. Via the stores, check that

the app is compatible with the operating system your

Smartphone is running.

Note: The ELICA manufacturer declares that this model of

household appliance with WiFi module radio equipment

complies with Directive 2014/53/EU.

The radio equipment operates within the 2.4GHz ISM

frequency band, the maximum radio frequency power

transmitted does not exceed 20 dBm (e.i.r.p.).

Warnings:

•  Data protection. The data that the connected device

detects is collected to allow for all the services of the

connected appliance to be used. Further information on

how the collected data is processed and on the privacy

policy is available at www.elica.com.

•  Availability in different countries. The Elica Connect

service is available in specific countries. For further

information, see the dedicated section at www.elica.com.

•  Future changes. Elica reserves the right to make any

changes deemed useful to improve the Elica Connect

service. As a result, the descriptions contained in this

manual are not binding and should be treated as purely

indicative.
