14

control system or any other device that switches on
automatically.


• This appliance is marked according to the European directi-
ve 2012/19/EC on Waste Electrical and Electronic Equipment
(WEEE).
• By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the envi-
ronment and human health, which could otherwise be caused
by inappropriate waste handling of this product.

• The symbol

 on the product, or on the documents

accompanying the product, indicates that this appliance may
not be treated as household waste. Instead it should be taken
to the appropriate collection point for the recycling of electrical
and electronic equipment. Disposal must be carried out in
accordance with local environmental regulations for waste
disposal.
• For further detailed information regarding the process, col-
lection and recycling of this product, please contact the ap-
propriate department of your local authorities or the local de-
partment for household waste or the shop where you purcha-
sed this product.

Appliance designed, tested and manufactured according to:
• Safety: EN/IEC 60335-1; EN/IEC 60335-2-31, EN/IEC
62233.
• Performance: EN/IEC 61591; ISO 5167-1; ISO 5167-3; ISO
5168; EN/IEC 60704-1; EN/IEC 60704-2-13; EN/IEC 60704-3;
ISO 3741; EN 50564; IEC 62301.
• EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR 14-2;
EN/IEC 61000-3-2; EN/IEC 61000-3-3. Suggestions for a
correct use in order to reduce the environmental impact:
Switch ON the hood at minimum speed when you start coo-
king and kept it running for few minutes after cooking is fini-
shed. Increase the speed only in case of large amount of
smoke and vapor and use boost speed(s) only in extreme
situations. Replace the charcoal filter(s) when necessary to
maintain a good odor reduction efficiency. Clean the grease
filter(s) when necessary to maintain a good grease filter effi-
ciency. Use the maximum diameter of the ducting system
indicated in this manual to optimize efficiency and minimize
noise.

Use

The hood is designed to be used either for exhausting

or filter version

.

Installation

The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the ran-
ge hood must be not less than 50cm from electric cookers and
65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a gre-
ater distance, this must be adhered to.
The mains power supply must correspond to the rating indica-
ted on the plate situated inside the hood. If provided with a

plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after installa-
tion. If it not fitted with a plug (direct mains connection) or if
the plug is not located in an accessible area, after installation,
apply a double pole switch in accordance with standards
which assures the complete disconnection of the mains under
conditions relating to over-current category III, in accordance
with installation instructions.


WARNING!

Before re-connecting the hood circuit to the mains supply and
checking the efficient function, always check that the mains
cable is correctly assembled.

Operation

The hood is fitted with a control panel with aspiration speed
selection control and a light switch to control cooking area
lights.

Maintenance


Clean using

ONLY

 the cloth dampened with neutral liquid

detergent.

DO NOT CLEAN WITH TOOLS OR INSTRU-

MENTS

. Do not use abrasive products.

DO NOT USE AL-

COHOL!

Grease filter
Fig. 11-23
The grease filter

 must be cleaned once a month using non

aggressive detergents, either by hand or in the dishwasher,
which must be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolor
slightly, but this does not affect its filtering capacity.

Charcoal filter (filter version only)
Fig. 22

The saturation of the

charcoal filter

 occurs after more or less

prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four months.
The charcoal filter may NOT be washed or regenerated.

Replacing lamps

The hood is equipped with a lighting system based on LED
technology.
The LEDs guarantee an optimum lighting, a duration up to 10
times as long as the traditional lamps and allow to save 90%
electrical energy.

For replacement, contact the technical service.
