maximum diameter of the ducting system indicated in this manual
to optimize efficiency and minimize noise.

Use

 Filtration version

The aspirated air will be degreased and deodorised before
being fed back into the room.
In order to use the hood in this version, you have to install a
system of additional filtering based on activated charcoal.


Mounting

Before beginning installation:

•

Check that the product purchased is of a suitable size for
the chosen installation area.

•  Remove the charcoal (*) filter/s if supplied (see also

relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.


Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this appliance to the wall.
Surface mounting only.


The product can be completed in height with the addition of
shelves with frame or extended in width by joining trusses,
with additional motor, additional light, shelves with frame.
All these accessories must be purchased separately.
Attention: check that the code of the Motor and additional light
kit indicated in this handbook in the illustrations section is the
same as that reported in the features label found in the motor
and light kit.

Elica Connect

The hood features a WiFi function for remote connection via
the Elica Connect app.
Minimum system requirements:
•

2.4GHz WiFi b/g/n wireless router

•

Android or iOs Smartphone. Via the stores, check that
the app is compatible with the operating system your
Smartphone is running.

Note:

The ELICA manufacturer declares that this model of

household appliance with WiFi module radio equipment
complies with Directive 2014/53/EU.
The radio equipment operates within the 2.4GHz ISM
frequency band, the maximum radio frequency power
transmitted does not exceed 20 dBm (e.i.r.p.).


Warnings:

•

Data protection.

The data that the connected device

detects is collected to allow for all the services of the
connected appliance to be used. Further information on
how the collected data is processed and on the privacy
policy is available at www.elica.com.

•

Availability in different countries.

The Elica Connect

service is available in specific countries. For further
information, see the dedicated section at www.elica.com.

•

Future changes.

Elica reserves the right to make any

changes deemed useful to improve the Elica Connect
service. As a result, the descriptions contained in this
manual are not binding and should be treated as purely
indicative.
