Installation

Mounting

Before beginning installation:

•  Check that the product purchased is of a suitable size for the

chosen installation area.

•  Remove the charcoal (*) filter/s if supplied (see also relative

paragraph). This/these is/are to be mounted only if you want

lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other supplied

material inside the hood (e.g. packets with screws (*),

guarantees (*), etc.), eventually removing them and keeping

them.

Expansion wall plugs are provided to secure the hood to most

types of walls/ceilings. However, a qualified technician must verify

suitability of the materials in accordance with the type of

wall/ceiling. The wall/ceiling must be strong enough to take the

weight of the hood.

Do not tile, grout or silicone this appliance to the wall. Surface

mounting only.

Mounting M1:

This type of cooker hood must be fixed to the ceiling.

Very heavy product; hood handling and installation must be

carried out by at least two persons.

Operation

To select the functions of the hood just touch the commands.

  Light key ON/OFF

Intensive speed selection key (suction power) -

duration 5 minutes:  the hood sets this power and

at the end of the 5 minutes returns to the previous

setting.

  High-speed selection key (suction power).

Medium-speed selection key (suction power) -

when flashing it indicates the need to wash or

replace the carbon filter. This signal is normally

deactivated. To activate the alarm, disable the

electronic by pressing the 0 button for 3 seconds.

Next, simultaneously press buttons 1 and 2 for 3

seconds; at first, only button 1 will flash, then both

buttons  1 and 2 will flash to indicate activation.

Repeat the procedure to deactivate the alarm; at

first buttons 1 and 2 will flash and subsequently

only button 1 to indicate deactivation.

Low-speed selection key (suction power) – when

flashing it indicates the need to wash the fats filter.

Motor key OFF (stand by) – excludes the

electronics – reset wash/replace filters signals.

MOTOR OFF

Press briefly to switch the motor off.

RESET FILTERS SIGNALS

In functioning mode, after carrying out filter

maintenance, press the key until hearing the sound

signal. The flashing LED 1  (grease filter) or 2

(carbon filter) stops flashing.

EXCLUDING THE ELECTRONICS

Press the key for 3 seconds. The hood command

electronics will be excluded.

This function can be useful during the product

cleaning operations.

Just repeat the operation to reinsert the electronics.

If the hood fails to operate correctly, briefly disconnect it from the

mains power supply for almost 5 sec. by pulling out the plug. Then

plug it in again and try once more before contacting the Technical

Assistance Service.

Maintenance

Cleaning

Clean using ONLY a cloth dampened with neutral liquid detergent.

DO NOT CLEAN WITH TOOLS OR INSTRUMENTS. Do not use

abrasive products. DO NOT USE ALCOHOL!

Grease filter

Fig. 11-25

The grease filter must be cleaned once a month using non

aggressive detergents, either by hand or in the dishwasher, which

must be set to a low temperature and a short cycle.  When washed

in a dishwasher, the grease filter may discolor slightly, but this

does not affect its filtering capacity.

Charcoal filter (filter version only)

Fig. 24

Circular charcoal filter

Apply one on each side as cover to both the shield grids of the

motor impeller, then turn clockwise.

For the disassembly, turn counter-clockwise.

The saturation of the charcoal filter occurs after more or less

prolonged use, depending on the type of cooking and the regularity

of cleaning of the grease filter.

In any case it is necessary to replace the cartridge at least every

four months.

The charcoal filter may NOT be washed or regenerated.

Replacing lamps

The hood is equipped with a lighting system based on LED

technology.

The LEDs guarantee an optimum lighting, a duration up to 10

times longer than the traditional lamps and allow to save 90%

electrical energy.

To replace lights, contact authorised spare part center.
