Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.


In the case of the presence of panels and/or walls and/or
lateral wall units check that there is sufficient space to install
the hood and that access to the command panel is easy.

An aesthetic flue can be purchased as an optional accessory.
Check with the assistance centre whether the model in your
possession envisages this possibility.
We advise installing the hood after having purchased the flue
to check with certainty the most suitable installation.


Operation

Use the high suction speed in cases of concentrated kitchen
vapours.  It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.


Model with touch panel


To select the functions of the hood just touch the commands.

1.  Button ON/OFF motor

Press this button to turn on the hood; the suction speed
(power)

1

 is selected.

With the hood on (at any speed), press this button to turn
the hood off.

2.  Button for suction speed (power) decrease

3.

Button for suction speed (power) increase

– the

selected speed can be distinguished from the colour of
the panel:

Suction speed (power) 1

: bright white

Suction speed (power) 2

: light blue

Suction speed (power) 3

: dark blue

Intensive

 s

uction speed (power)

: flashing dark blue

Note:

Intensive suction speed (power) is active for a

limited time

(approximately 5 minutes) after which the

hood is automatically positioned at suction speed (power)

2

.

4.  Button ON/OFF lighting/lights

Saturation indicator

The hood is equipped with a system that can notify via a
dedicated indicator, when it is necessary to perform
maintenance of the filters.
The grease filter saturation indicator is always active.
Check the saturation status of the charcoal filter:
Turn off the hood.
Press and hold button

2

 for 2 seconds.

Important!

 Do not hold the button longer, this may change the

saturation indicator related settings (see next paragraph

"Activation of the saturation indicator of the charcoal
filter"

).

Flashing lighting of the panel

: the saturation indicator of the

charcoal filter is disabled, the hood is ready to operate in
ventilation version.
To use the hood in filtering version, the saturation indicator of
the charcoal filter should be activated.

Steady lighting of the panel

: the saturation indicator of the

charcoal filter is activated, the hood is ready to operate in
filtering version.
To use the hood in ventilation version, the saturation indicator
of the charcoal filter should be disabled.

Activation of the saturation indicator of the charcoal filter:

Turn off the hood.
Press and hold button

2

for longer than 5 seconds.

Panel lighting will change from "flashing" to "steady" to
indicate that activation was successful.

Disabling of the saturation indicator of the charcoal filter:

Turn off the hood.
Press and hold button

2

for longer than 5 seconds.

Panel lighting will change from "steady" to "flashing" to
indicate that activation was successful.


Filter saturation indicator

The panel lights up at regular intervals:

in steady red,

 to indicate that it is necessary to perform

maintenance of the grease filter

in flashing red

, to indicate that it is necessary to perform

maintenance of the charcoal filter.

To reset the saturation indicator:

Turn off the hood.
Press and hold button

2

 for approximately 5 seconds.

Perform filter maintenance.

Temperature Alarm

The hood is equipped with a temperature sensor that activates
the motor in the event that the temperature in the control area
is too high.
This state persists until the temperature falls below the alarm
threshold.

Temperature Alarm

The hood is equipped with a temperature sensor which
activates the motor in case the temperature in the control
panel  zone is too high.
This condition remains as such until the temperature falls
below the alarm threshold.
