8

Use

The hood is designed to be used either for exhausting or filter
version.

Ducting version

The cooker hood is provided with an upper air exit

A

 with

connection ring

B

, a discharge tube (not provided) should be

mounted on the ring for discharging fumes and vapours
externally.

Attention! If the hood is supplied with carbon filter, then it
must be removed.

Filter version

When there is no exhaust duct for venting outdoors, you can
use a carbon filter.
The air is depurated by the filter and put again in the
surrounding. To use the appliance in this version, proceded as
follows:
The air is vented outdoors by a duct, passing througt the wall
units and connected to the connecting ring.

Attention! If the hood is not supplied with carbon filter,
then it must be ordered and mounted.

The models with no suction motor only operate in ducting
mode, and must be connected to an external suction device
(not supplied).
The connecting instructions are supplied with the peripheral
suction unit.

Installation

The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the
range hood must be not less than 65cm from electric cookers
and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation,  apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in
accordance with installation instructions.

Warning!

 Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that
the mains cable is correctly assembled.

Mounting

Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.

This hood is designed for fitting in a cabinet or on some other
support.
Carry out the following instructions for affixing the cooker
hood:
Create an opening in the bottom of the cabinet to insert the
cooker hood, and drill a hole on the top of the cabinet to fit the
discharge tube, connect the cooker hood to an external pipe,
predispose the electrical connection, remove the grill or the
anti-grease filter, remove the frame

C

 (if provided) by pressing

on the two release hooks

D

(according to the model in

possession, the release hook button

D

 may be located

externally or inside the cooker hood below the grease filter /
grill), insert the cooker hood in the opening (lock in the lateral
clasps

E

 if provided by tightening the locking screws

F

), finally

fix the cooker hood to the cabinet with wood screws

G

supplied.  Remount the frame

C

 (if provided), and suction grill

H

.
