- 19 -

•  FIXING THE  HOOD TO THE  LOWER  PART  OF THE
WALL CABINET

This type of appliance must be fitted inside a cabinet or
inside another type of suppor t structure. To fix it in place,
use 4 screws which are suitable for the type of cabinet,
making holes in accordance with the diagram shown in
(fig. 1). To fit the appliance correctly, align the front panel
of the cooker hood with the cabinet door and adjust
spacer

E

  u s i n g   s c r ew s

P

  ( f i g .  2 ) ,   t h e n   e n s u r e   t h e

appliance meets the cabinet at the rear.

•

EXTRACTION THROUGH AN OUTSIDE WALL

The appliance expels the fumes through an outside wall
or a duct.  It is necessary to buy a telescopic pipe in
accordance with the standards in use (inflammable)  and
connect it to flange

B

 (Fig 3).

•

RECIRCULATION

To transform the cooker hood from the extraction version
to the re circulating one ask your supplier for an activated
carbon filter.
The filter must be fitted to the extracting group cooker
hood in the centre of the fan grille by twisting it by 90
degrees until it is gripped securely (Fig 6).  For this
operation remove the anti-grease filter(s)

G

 (Fig 5).  The

clean air is retur ned into the room through a connecting
tube passing inside the cupboard and connected to the
ring

B

 (fig 4).

USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on

before any food is cooked. We also recommend that the
appliance is left running for 15 minutes after the food is
cooked, in order to thoroughly eliminate all contaminated
air.
The effective performance of the cooker hood depends
on constant maintenance; the anti-grease filter and the
active carbon filter both require special attention.
• The anti-grease filter is used to trap any grease particles
suspended in the air, therefore is subject to saturation
(the time it takes for the filter to become saturated
depends on the way in which the appliance is used).
The acr ylic filter, which is found resting on the grille,
should be replaced when the text, visible through the
grille, changes colour and the ink spreads; the new filter
should be fitted in such a way that the text can be seen
through the grille from outside the cooker hood.
If the filters do not have any text on them, or if metal
filters or aluminium panel filters are used, they should
be washed every 2 months in order to prevent the risk of
fire. To wash the filters, proceed as follows:
- Remove the filter from the grille and wash it using a
solution of water and neutral liquid detergent, leaving
the dir t to soften.
- Rinse thoroughly with warm water and leave to dry.
T h e   m e t a l   f i l t e r s   a n d / o r   a l u m i n i u m   p a n e l   a r e   a l s o
dishwasher safe. If the filters are made using aluminium,
or if an aluminium panel is used, after a few washes the
colour may change. This does not mean they have to be
replaced.
If the replacement and washing instr uctions are not
followed, the anti-grease filters may present a fire hazard.
• The active carbon filters are used to purify the air which
is released back into the room. The filters are not
washable or re-usable and must be replaced at least once
every four months. The active carbon filter saturation level
depends on the frequency with which the appliance is
used, the type of cooking perfor med and the regularity
with which the anti-grease filters are cleaned.

•

Remove build-up from the fan and other surfaces of

the cooker hood regularly using a cloth moistened with

d e n a t u r e d   a l c o h o l   o r   n o n - a b ra s i ve   n e u t r a l   l i q u i d
detergent.
• The light on the cooker hood is designed for use during
cooking and not for general room illumination. Extended
use of the light reduces the average duration of the bulb.

• Replacing halogen light bulbs (Fig. 8).

To replace the halogen light bulbs

B

, remove the glass

pane

C

 using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution:

 do not touch the light bulb with bare hands.

MICROSWITCH (fig. 9).
Warning!

This hood is fitted with a

microswitch

 which

allows the activation of the functions (light and motor
s p e e d )   t h r o u g h   t h e   o p e n i n g   o f   t h e   t e l e s c o p i c
undercarriage.
If the telescopic undercarriage is closed, neither the lights
nor the motor speed can be activated (fig. 9).

•COMMANDS:

(pic.9)

SLIDER

the key symbols are ex-

plained below:

A

   = Light switch

A1

 = Off key

A2

 = On key

B

   = Speed control

B1

 = Off key

B2

 = FIRST SPEED key

B3

 = SECOND SPEED key

B4

 = THIRD SPEED key

• COMANDI:

 (Fig.7)

SLIDER

the key symbols are

explained below:
This hood is fitted with a

microswitch

 which allows the

activation of the motor speed) through the opening of
t h e   t e l e s c o p i c   u n d e r c a r r i a g e .  I f   t h e   t e l e s c o p i c
undercarriage is closed the motor speeds cannot be
activated.
T h i s   m i c r o sw i t c h   d o e s   n o t   h ave   a n   i m p a c t   o n   t h e
activation of the lights which must be switched on through
the appropriate switch (see fig.7A).

A

   = Light switch

A1

 = Off key

A2

 = On key

B

   = Speed control

B1

 = FIRST SPEED key

B2

 = SECOND SPEED key

B3

 = THIRD SPEED ke

Warning!

If the telescopic undercarriage is closed with

the speed set at 2,, once it is re-opened, the hood will
be reactivated with the same speed in use when the hood
was closed.

T H E   M A N U FAC T U R E R   D E C L I N E S   A L L
R E S P O N S I B I L I T Y   F O R   E V E N T UA L   DA M A G E S
CAUSED BY BREACHING THE  ABOVE WARNINGS.
