14
15
INSTALLATION
•
The minimum distance between the sup-
port surface of containers on the cooking
device and the lowest part of the kitchen
hood shall not be lower than the ones
indicated in the figure (s) relating to the in
-
stallation for the different types of cooking
devices (Gas hob: 650mm / Electric hob:
500mm). If the installation instructions of
the gas hob require a greater distance,
this must be taken into account (Fig. 2).
•
Do not connect the appliance to the mains
until installation is fully completed.
•
As for the technical and safety measures
to be adopted for the discharge of fumes,
strictly comply with the provisions of the
regulations specified by the competent
local authorities.
•
Extracted air shall not be conveyed into
a duct used for the discharge of fumes
produced by appliances burning gas or
other fuels.
•
Do not use or leave the hood without its
lamps properly fitted, as it may result in
potential electric shock risk.
•
NEVER use the hood without its grid/
filters properly fitted!
•
The hood should NEVER be used as
a support surface unless specifically
indicated. The maximum total weight of
any objects positioned or hung on the
hood (where applicable), must not exceed
1.5Kg.
•
For installation, use only the fixing screws
supplied with the appliance or, in case
they are not supplied, purchase the correct
type of screws.
•
Use screws with the correct length speci-
fied in the documentation.
•
Contact the authorized service center
or similar qualified personnel in case of
doubts.
CAUTION!
Failure to install screws and fixing
devices in accordance with these instructions
may result in electrical risk.
Do not use the appliance with a programmer,
timer, separate remote control, or any other
device that activates automatically.
ASSEMBLY
Before starting installation:
•
Check that the product purchased is of a
suitable size for the area where it is to be
installed.
•
Check that (for transportation purposes)
there is no material inside the hood (e.g.
bags with screws, warranties, etc.), which
needs to be removed and stored for future
use.
Follow the installation instructions specified
below:
1. The appliance shall be installed at the re-
quired distance from the cooking surface
(Gas hob : 650mm / Electric hob: 500mm)
- (Fig. 2).
2.
Remove the three metal grease filters
(Fig.3-B).
3. Drill the holes on the wall according to the
template provided (see Fig. 4).
4.
Use the inserts to fix the hood (Fig. 5).
5. Hang the hood on the wall (A), and secure
it with the screws (C) (Fig.6).
6. Position the bracket (D) and secure it to
the wall (B) (Fig. 6).
7. Adjust the telescopic chimney elements
and secure it to the bracket (D) (Fig.7).
CAUTION!
Heavy-weight product: hood handling and in-
stallation should be carried out by at least two
people or more.
