English |

17

(2)

Motor unit

(3)

Fastening screw for safety cover or vacuum tube

(4)

Safety cover (blow mode)

(5)

Handle on vacuum tube (vacuum mode)

(6)

Screw for handle adjustment

(7)

Vacuum tube (vacuum mode)

(8)

Hook for shoulder strap

(9)

Shoulder strap

(10)

Collection bag (vacuum mode)

(11)

Button for unlocking nozzle or collection bag

(12)

Nozzle (blow mode)

(13)

Loop for shoulder strap hooks

Technical Data

Leaf blower/Garden Va-
cuum Cleaner

UniversalGardenTidy

UniversalGardenTidy

2300

UniversalGardenTidy

3000

Article number

3 600 HB1 000
3 600 HB1 030

3 600 HB1 070

3 600 HB1 002
3 600 HB1 032

3 600 HB1 072

3 600 HB1 001
3 600 HB1 041

3 600 HB1 071

Rated power input

W

1800

1600 − 2300

1600 − 3000

Airflow speed, max.

km/h

165 − 285

165 − 285

165 − 285

Volume flow rate, max.

l/s

160

160

160

Shredding ratio

12:1

12:1

12:1

Collection bag capacity

l

45

45

50

Weight (blow mode)

kg

3.4

3.4

3.4

Weight (vacuum mode)

kg

4.7

4.7

4.7

Protection class

 / II

 / II

 / II

Serial number

see type plate on product

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Noise/Vibration Information

Vacuum Mode

Blow Mode

Noise emission values determined according to

EN 50636-2-100

.

Typically the A-weighted noise levels of the product are:

– Sound pressure level

dB(A)

86

83

– Sound power level

dB(A)

98

96

– Uncertainty K

dB

= 2.5

= 2.5

Vibration total values a

h

 (triax vector sum) and uncertainty K determined according to

EN 50636-2-100

– Vibration emission value a

h

m/s

2

< 2.5

< 2.5

– Uncertainty K

m/s

2

= 1.5

= 1.5

Blow Mode

Assembly (see figure B)

u

Before any work on the product, disconnect supply
cord from the mains.

Slide the nozzle

(12)

 onto the motor unit. Take care not to

pinch your fingers during assembly.
Mount the safety cover

(4)

 onto the motor unit. For this,

place the safety cover

(4)

 into the hinge on the motor unit.

Position the safety cover

(4)

 against the motor unit and

screw in fastening screw

(3)

 until fully tight and clicks are

heard to secure the safety cover.

Operating (see figures C and D)

Make sure that the cable is not in your way while working.
To

switch on

, turn the On/Off switch

(1)

 clockwise until it

clicks.
The airflow speed is variable. To increase the airflow speed,
turn the On/Off switch

(1)

 clockwise.

To reduce the speed, turn the On/Off switch

(1)

 anticlock-

wise.
To

switch off

, turn the On/Off switch

(1)

 anticlockwise until

it clicks.
Set the On/Off switch

(1)

 of the product to "0" before dis-

connecting the mains voltage or pulling the mains plug.
