www.timberk.com • instant water heater

4

Table 1a

ATTENTION!

The water heater shall be certainly grounded.

3. APPLICATION OF WATER HEATER

4. SPECIFICATIONS

Electric water heater is used to heat cold water from water supply. Unit is

for household use.

The water heater shall be operated only with an original shower nozzle and/or

kitchen spout excluding their clogging.
25. The water heater is designed only for heating of water. Do not use the

product for heating of other liquids. This may inflict a severe damage to the

water heater.
26. Do not connect electric wires of the device to a water pipeline, a gas

pipeline, etc.
27. Make sure in proper connection of electric wiring (including grounding

loop).
28. Before use, make sure that parameters of your electric mains meet the

specifications of this water heater.
29. Inlet temperature of water shall not exceed +35°C.
30. For use of the water heater in a bathroom, it is recommended to install it

above body height so that water splashes do not get onto its enclosure.

It is expressly PROHIBITED to
•

Pull electric wires inside the water heater;

•

Remove the enclosure of the water heater, when it is energized;

•

Install other fixtures, except for fixtures recommended by the

manufacturer;

Specifications for different series of water heaters are given in Tables 1a, 1b,

1c.

Parameter

Unit of

measuremen

WHEL-3 OC

WHEL-3 OS

WHEL-3 OSC

Version

-

crane

shower

shower+crane

Power supply parameters

V/Hz

220~/50

220~/50

220~/50

Rated current

A

16

16

16

Power by steps

kW

0/3,5

0/3,5

0/3,5

Rated power consumption

kW

3,5

3,5

3,5

Operating pressure

Mpa

0,03 - 0,6

0,03 - 0,6

0,03 - 0,6

Flow rate (at t=20°C)

L/min

1,9

1,9

1,9

Protection class

-

I

I

I

Water protection class

-

IPX4

IPX4

IPX4

Wire section of electric connection

cabel

mm2

3 х 1,5

3 х 1,5

3 х 1,5

Dimensions

mm (H х W

х H)

159x272x112

159x272x112

159x272x112

Net weight

kg

1,35

1,35

1,35
